Specifications for Perforated Steel U Channel Sign Posts
Steel sign post manufacturer
1.OEM service is offered
2.drawing or sample is available
3.excellent quality and cheap price
Commodity information: Sign post
* Specification:
A. U Channel Post:1.12lb per ft (green)
B. U Channel Post: 2lbs per ft (galvanized) also available in green
C. U Channel Post: 2.5-4lbs per ft (galvanized)
D. Square Post. perforated 4 sides(galvanized)
E. Square post with know-out plugs(galvanized)
F. Square post with know-out plugs(powder coated)
G. Round post, tubular post 2 3/8'' O.D.(galvanized)
* Making request:
Holes are 3/8'' diameter spaced 1''on center for easy sign mounting
Punched full-length, tapered ends for easy installation
Flanged channel sign posts manufactured in a variety of lengths in the weight of 2lb per linear foot
Standard finish is hot-dip galvanized or available in a variety of powder coated colors
* Minimum yield strength: 60,000psi
* Minimum tensile strength: 80,000psi
Steel Square Tube for Traffic Sign Support,Sign Post
Square Post | |
Steel plate |
ASTM A1011 or ASTM A653 Grade 50 Structural quality |
Tolerance |
Min yield strength: 50,000 PSI (340 MPa) |
Max tensile strength |
79,000 PSI (540 MPa) |
Galvanizing type |
Zinc primer, hot-dip galvanized, ASTM A653 G90 |
Sizes |
1 1/2", 1 3/4", 2", 2 1/4" and 2 1/2" square. |
Product can be done according to customers' requirements.
U Channel Sign Post | |
Min tensile strength |
80,000 psi |
Min yield strength |
100,000 psi |
Dimensions |
Available in 7-, 8-, 10-, 12-, 14- and 16-foot lengths or as customer's request. |
Holes are 3/8'' diameter spaced 1''on center for easy sign mounting | |
Flanged channel sign posts manufactured in a variety of lengths in the weight of 2lb or 1.2lb per linear foot | |
Standard finish is hot-dip galvanized or available in a variety of powder coated colors | |
Notes: Other sizes are available upon request.
Company Profile:
Jinan Rainbow Metalwork Co., Ltd is a professional U channel sign post , square sign post and sign blanks manufacturer with many years experience. Our products are sold to North American for 6 years.
Also we have offices in Seattle WA,United States. If you have never imported goods from China, we can provide the whole process from production to shipment directly to you. We can manage the customs clearance and inland transportation.
We could make all kinds of traffic sign posts according to your drawings or samples! Looking forward to your inquiry and I believe you will never regret to choose us!
