Wall Mounted Rack
Feature
1.Welded frame,stable structure with precise craftsmanship;
2.Double section,compatible 19"standard equipment;
3.Tempered glass front door with over 180 turning degree;
4.Removable side panel,easy to install and maintain(lock optional);
5.Cable entry on the top cover and bottom panel with knock-out plate;
6.L-shaped mounting profile,easy to adjustable on the mounting rail;
7.Fan cutout on the top cover ,easy to install fan;
8.Swing back with over 90 turning degree;
9.Various accessories for optional;
Material
SPCC cold rolled steel
Thickness: mounting profile: 1.5mm,others: 1.2mm
Loading Capacity:static loading:60kg
Degree of protection:IP20
Surface Finish :Degreasing, Pickling, phosphoric, Powder coated
Main Component
Optional Accessories:
Removable side panel can add the lock;Fixed Shelf,
Various of front door
Ornament strip for the glass side
Brush for cable entry and other design
Smoked color glass
Cantilever
Main Machine
Certification
