Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Digital Fusion Splicer

Digital Fusion Splicer

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

Model Number:

KL-300T Fusion Splicer

Contact Supplier Request Quote Chat Now

Ningbo Latitude International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai/Customer Required Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name LE

Model Number KL-300T Fusion Splicer

Specifications

Digital fusion splicer
optical fiber joint equipment fusion splicer
3.5-inch color display, while observing the X-axis, Y-a

Digital fusion splicer

Features

Core to core alignment by PAS technology

( PAS:Profile Alignment System)
Digital fusion splicer with automatic focus function

Fiber core can be display clearly
Single X or Y view and X & Y view simultaneously
Auto detect cleaved endface fault
Display fiber cleaved and offset angle
Display core and clad offset
5.6 inch TFT color LCD monitor with clear digital image display
USB & VGA interface
Software upgrade via USB interface

Specefications

Model	KL-300T
Applicable fibers	SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655)
Fiber cleaved length	12~16mm(Coating diameter:250µm) 16mm(Coating diameter: 250 ~ 1000µm)
Fiber diameter	Cladding diameter:80 ~150µm Coating diameter:100~ 1000μm
Fiber Count	Single
Fiber aligning method	Core or clad aligning
Image processing method	Digital
Actual average splice loss	0.02dB(SM), 0.01dB (MM),0.04dB (DS), 0.04dB( NZDS)
Splicing time	Typical 9 sec,with standard SM fiber
Splicing mode	53(templet), 40(user)
Splice loss estimate	More accurate
Return loss	>60dB
Storage of splice result	4000 results,20 parameter per result
Fiber display and magnification	300X(X or Y view),150X(X and Y view)
Tube heating time	Typical 30 sec
Tube heating mode	9(templet), 24(user)
Tube heating temperature	Can be adjusted
Applicable Protection sleeve length	60mm, 40mm and a series of micro sleeves
Tension test	2N
Electrode life	2500
No.of splice/heating with battery	Typical 150 cycles (splice/tube heat) with inner Li-battery
Display screen	5.6 TFT inch color LCD monitor
Image change over	The fiber image is turned upside down
Terminals	USB 1.1 and VGA
Operating condition	0 ~ 5000m above sea level, 0 ~ 95%RH and -10~50°C, respectively, Max. wind velocity of 15m/s
Power supply	AC 100-240V with AC adapter; inner Li-battery(6600mAH)
Dimensions	150mm(L) x150mm (W) x150mm (H)
Weight	2.7 Kg excluding battery,3.2 Kg including battery

Functions

Model	KL-300T
Splicing mode	Auto Calibrate Normal Special
Fiber cleaved angle threshold set	0.1 - 10.0 ° 0.1°step
Display fiber cleaved angle	.
Display fiber offset angle	.
Auto focusing	-
Auto aligning	.
Auto detect cleaved endface fault
Display core offset	.
Display clad offset	.
Fiber partial core Compensation	.
Arc strength automatic adjustment	.
Display inside temperature	.
Display ambient temperature	.
Display heater temperature	.
Display air pressure	.
Display battery voltage	.
Taper Splice	.
Sleep	.
Auto Shut down	.
Software upgrade	.
.:Available -:Unavailable
