Specifications
Bulb and capillary thermostats (Liquid expansion measurement)Model:Y1G8
Thermostat : 8G
Main features:
Remote control in usual industrial application and environment, not hazardous areas.
Internal adjustment is convenient for products that must not be frequently adjusted.
Standard electrical and mechanical life model
Temperature range: numerous from -35 to +320°C
Housing: Aluminum,IP65, IK10, 104 x 102 x 86 mm. Mounted on a SUS304 stainless steel wall mounting plate. Grey RAL7032 epoxy painting
Set point adjustment ranges: -35+35°C (-30+95°F), -10+40°C (15-105°F), 4-40°C (40-105°F), 30-90°C (85-195°F), 30-110°C (85-230°F), 50-200°C (120-390°F), 50-300°C(120-570°F).
Temperature adjustment: Set point adjustable by temperature printed internal knob. Shipped with °C printed skirt fitted on the knob, and °F printed skirt in spare part. Printed
skirt is replaceable without tool.
Action: temperature control.
Sensing element: Liquid expansion bulb and capillary. The capillary is protected by a stainless steel corrugated pipe terminated by a silicone tip. A plastic cap plug provided as standard accessory allows locking the flexible metal conduit inside a pocket (See pockets in the accessories section)
Electrical connections: Inside, on screw terminal connection block
Earthing: on internal screw terminal
Cable output: M16 cable gland, PA66, for cables up to 10 mm dia.
Mounting: Wall mounting, by 4 holes for screws dia. 4 to 5 mm, 94 x 92 mm distance
Identification: 20 x 40 mm stainless steel identification label, riveted.
Contact: SPDT
Electrical rating:
- Open on temperature rise contact (C-1) 16A(2.6) 250VAC
- Close on temperature rise contact (C-2) 6A(0.6) 250VAC
- Electrical life >100.000 cycles.
Cannot be used in 400VAC
Minimum Storage temperature: -35°C (-30°F)
Reference
|
Temperature adjustment ranges °C (°F) |
References |
Differential °C (°F) |
Capillary length (C, mm) |
Bulb diameter (D, mm) |
Bulb length (E, mm) |
Max. temperature on bulb °C (°F) |
-35+35°C (-30+95°F) |
Y1G8GB-35035AO6G |
3±2°C (5.5±3.6 °F) |
1500 |
6 |
98 |
55°C (130°F)
|
-10+40°C (15-105°F) |
Y1G8GB-10040AO6G |
3±2°C (5.5±3.6 °F) |
1500 |
6 |
120 |
60°C (140°F)
|
4-40°C (40-105°F) |
Y1G8GB004040AO6G |
3±2°C (5.5±3.6 °F) |
1500 |
6 |
140 |
60°C (140°F)
|
30-90°C (85-195°F) |
Y1G8GB030090AO6G |
4±3°C (7±5.5 °F) |
1500 |
6 |
87 |
120°C (250°F)
|
30-110°C (85-230°F) |
Y1G8GB030110AO6G |
5±3°C (9±5.5 °F) |
1500 |
6 |
83 |
150°C (300°F)
|
50-200°C (120-390°F) |
Y1G8GB050200AO6G |
8±5°C (14.5±9 °F) |
1500 |
6 |
59 |
250°C (480°F)
|
50-300°C (120-570°F) |
Y1G8GB050300AO3G |
10±5°C (18±9 °F) |
1500 |
3 |
165 |
350°C (660°F)
|
