Specifications
Fan heaters and convection heaters, 130mm rangeUpward blowing models, electronic control
Type 9CK
Main applications
These heavy duty fan heaters, are designed for professional, commercial or industrial applications.
They are equipped with 3 silent high flow fans, and a waterproof control box equipped with a 2 pole, illuminated on-off switch, an electronic temperature control with digital display, a safety thermostat, and a tip over switch.
Although their heating elements and control boxes are waterproof, their fans are not, and they should not be used outdoors without proper protection of the hot air outlets against liquid drops and rain.
For outdoor application, use the models without fans. Their insulation class 1 does not allow using them in bathroom and in all places requiring Class II insulation. They are not designed for use in hazardous environments.
They exist with painted steel or stainless steel frame.
The main applications are heating of professional workshops, bungalows, cranes cabins, construction equipment, wagons or locomotives cockpit, technical rooms, ovens, containers, dryers.
Main features
Dimensions: 450 mm x130x 150mm body (control box and legs not included) Ingress protection: IP40 (fan heater version) or IP65 (version without fans)
Heaters: 3 finned elements in 304L stainless steel. Fins 25x50mm 304 stainless steel. Surface load 3W/cm² for fan models and 2W/cm² for no fan models.
Frame material: 0.8mm thick sheet, high strength (Withstands +100kg distributed load), two versions:
- Galvanized steel sheet with black epoxy paint
- 304 stainless steel sheet.
3 Fans (only for version with fans): 3 fans of 120 x 120mm, flow 3 x 30m /h. L10 life expectancy: 50.000 h (>5 years) at 25ºC. L10 refers to the time at which statistically, 90% of the fan will still be operative. Life expectancy is reduced by about 50% when ambient temperature rises to 50-70°C.
Controls:
Located inside a PA66, IK10 protection box, with sealable window, providing access to:
- Electronic temperature control, with differential adjustment, digital display at 1/10°, temperature range 4-40°C (can be set in °F)
- Fail safe high limit manual reset thermostat for protection against air outlet obstruction or fans failure
- Tip-over switch to protect against heater fail over
Electrical connection: by grounded euro plug, 2 meters, 3x1.5mm² (no cable supplied in the 3 phase version)
Mounting: 2 removable legs can be mounted under the frame (floor mounting) or on the side (wall mounting).
Voltage: single phase 230V, 50/60Hz or 400V three phase with neutral
Power:
-IP40 single phase, 230V: 2000W, 3500W ; 3 phases: 4000W
-IP65 single phase, 230V: 1300W, 2600W ; 3 phases: 2600W
Ambient temperature : -20 to +60 ° C
Net weight: 8.4 kg
Option:
-Infrared on-off remote control
-Customization accepted
References, IP40 version with fans |
References, IP65 version without fans |
||||||||||
Black painted steel frame |
304 stainless steel frame |
Black painted steel frame |
304 stainless steel frame |
||||||||
References |
Power (W) |
Voltage |
References |
Power (W) |
Voltage |
References |
Power (W) |
Voltage |
References |
Power (W) |
Voltage |
9CK34Y33023200HB |
2000 |
230 |
9CK34Y33023200H4 |
2000 |
230 |
9CK3DY32023130HB |
1300 |
230 |
9CK3DY32023130H4 |
1300 |
230 |
9CK34Y63023300HB |
3500 |
230 |
9CK34Y63023300H4 |
3500 |
230 |
9CK3DY23023260HB |
2600 |
230 |
9CK3DY62023260H4 |
2600 |
230 |
9CK34Y630433000B |
4000 |
3x400 |
9CK34Y6304330004 |
4000 |
3x400 |
9CK3DY620432600B |
2600 |
3x400 |
9CK3DY6204326004 |
2600 |
3x400 |
