Help Center105mm-800mm Laser Welded Segments Diamond Saw Blades for Concrete,stone, Granite Segmentes Marble Cutting Disc
Related Products
-
Exceptional Performance Silver Brazed Diamond Saw BladeUS$ 20 - 100MOQ: 50 Pieces -
15pcs BI-Metal Hole Drill Saw SetUS$ 2 - 5MOQ: 100 Pieces
-
13pcs BI-Metal Hole Saw SetUS$ 2 - 5MOQ: 100 Pieces
-
9pcs BI-Metal Hole Saw SetUS$ 2 - 5MOQ: 100 Pieces
-
TCT Cutter for MetalUS$ 0.8 - 10MOQ: 100 Pieces
Product Description
Laser welding technology enables the manufacturing process to be highly automated,resulting in greatly improved stability and stronger adhesion of the diamonds to the metal substrate.The result is improved efficiency ,cutting life and operator safety.
Application of General Purpose Laser Welded Blade: Designed for high performance -cutting of an extensive range of masonry marble ,asphalt ,granite and concrete material including bricks, blocks,slate,stone,etc.
Features
- For Cutting on Asphalt/Green Concrete
- Laser Welded Technology Makes It High Densety,Longer Lifetime and Sharpness.
Specifications
| Outer diameter | Bore | Segment | Segment | |
| mm | inch | diameter(mm) | Width(mm) | Height(mm) |
| 230 | 9" | 22.23 | 2.5 | 8/10 |
| 250 | 10" | 25.4/22.23 | 2.6 | 8/10 |
| 300 | 12" | 50/25.4 | 3.2 | 8/10 |
| 350 | 14" | 50/25.4 | 3.2 | 8/10 |
| 400 | 16" | 50/25.4 | 3.4 | 8/10 |
| 450 | 18" | 50/25.4 | 3.6 | 8/10 |
| 500 | 20" | 50/25.4 | 3.8 | 8/10 |
| 550 | 22" | 50/25.4 | 4.2 | 8/10 |
| 600 | 24" | 50/25.4 | 4.4 | 8/10 |
Laser Welded Diamond Saw Blade :
| 1st GENERAL PURPOSE(KEY SLOT) |
| 2nd ASPHALT/GREEN CONCRETE(DEEP SEGMENT) |
| 3rd ASPHALT/GREEN CONCRETE(TCT INSERTED) |
| 4th ASPHALT/GREEN CONCRETE(DROP SEGMENT) |
| 5th ASPHALT/GREEN CONCRETE(DEEP-DROP SEGMENT) |
| 6th CURED CONCRETE(SHORT SEGMENT) |
| 7th CURED CONCRETE/GRANITE(TURBO SEGMENT) |
| 8th CURED CONCRETE/GRANITE(W-SHAPE SEGMENT) |
| 9th CURED CONCRETE/GRANITE(S-SHAPE SEGMENT) |
| 10th CURED CONCRETE/ASPHALT(DROP SLOT) |
| 11th CURED CONCRETE/ASPHALT(WIDE SKEW U SLOT) |
| 12th CURED CONCRETE/ASPHALT(MIXED SEGMENT) |
| 13th GRANITE/MARBLE(NARROW U SLOT) |
Silver Brazed Diamond Saw Blade:
| 1st Straight Slot Silver Brazed Diamond Saw Blade | |||
| 2nd Key Slot Silver Brazed Diamond Saw Blade | |||
| 3rd Fishhook Slot Silver Brazed Diamond Saw Blade |
Hot Press Sintered Diamond Saw Blade:
| 1st HOT PRESS SINTERED SEGMENTED |
| 2nd HOT PRESS SINTERED CONTINUOUS RIM |
| 3rd HOT PRESS SINTERED TURBO |
| 4th HOT PRESS SINTERED TURBO WAVE |
| 5th HOT PRESS SINTERED SUPER THIN TURBO |
| 6th HOT PRESS SINTERED FINE TURBO |
| 7th HOT PRESS SINTERED TURBO(SEGMENTED) WITH PROTECTIVE TEETH |
Cold Press Sintered Diamond Saw Blade:
| 1st COLD PRESS SINTERED SEGMENTED |
| 2nd COLD PRESS SINTERED CONTINUOUS RIM |
| 3rd COLD PRESS SINTERED TURBO |
| 4th COLD PRESS SINTERED TURBO WAVE |
| 5th COLD PRESS SINTERED FINE TURBO |
| 6th COLD PRESS SINTERED TURBO SEGMENTED |
Product Picture
- Existing samples: free of charge. Sampling time: 3-5 days.
- Customized samples: charging according to the cost; returing after placing orders. Sampling time: 2 weeks.
Our Advantages
- Low MOQ: It can meet your promotional business very well.
- OEM Accepted : We can produce any your design.
- Good Service : We treat clients as friends.
- Good Quality : We have strict quality control system and good reputation in global market.
- Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
Check below for more information on placing an order
1. Inquiry - Professional quotation. |
2. Confirm the price, lead time, payment term etc. |
3. POWERSKY Tools sales send the Proforma Invoice with POWERSKY Tools seal. |
4. Client makes the payment for deposit and send us Bank receipt. |
|
5. Initial Production Stage - Inform the clients that we have got the payment, and will make the samples according to your request, send you photos or samples to get your approval. After approval, we inform that we will arrange the production & inform the estimated time. |
|
6. Middle Production - send photos to show the production line which you can see your products in. Confirm the estimated delivery time again. |
|
7. End Production - Mass production products photos and samples will send to you for approval. You can also arrange the third party inspection. |
|
8. Clients make payment for balance and POWERSKY Tools ship the goods. Also can accept payment term - Balance against B/L copy or L/C payment term. Inform the tracking number and check the status for clients. |
9. Order can be say “finish” when you receive the goods and satisfy with them. |
