Help CenterChamp PCB Mounting Amphenol Right Angle Solder DIP 24 Way Connector 2.16mm Pitch Female Socket
Related Products
-
DDK DIP Female Receptacle Type PCB Mount Right Angle Amphenol Connector 24 Pin 2.16mm PitchUS$ 0.5 - 2MOQ: 1000 Pieces -
57 Series DDK 40 Type Receptacle Female 24 Pin Socket Connector Right Angle PCB MountUS$ 0.5 - 2MOQ: 1000 Pieces
-
24P Female DDK PCB Mounting Right Angle Terminals Centronics Connector for PCB BoardUS$ 0.5 - 2MOQ: 1000 Pieces
-
57-24 Pin Female Receptacle Right Angle PCB Mount Connector With Spring LatchesUS$ 0.5 - 2MOQ: 1000 Pieces
-
DDK Female Recetpacle Type PCB Mount Right Angle 0.085in Pitch Centronics Connector 24PinUS$ 0.5 - 2MOQ: 1000 Pieces
Specifications
1) Common Features
| Designed for Cable-to-cable and cable-to-PC Board applications | |
| Board Application | |
| Available in Plug & Socket styles | |
| Terminal Option with various types | |
| Connector and hood sold as complete assembly | |
| Available in low profile hood style | |
| Metal shell provides grounding and shielding capability | |
| Mates with industry compatible connector |
2) Product features
1. Product Type: Connector
2. Product Line:CENTRONIC
3. Connector Style: Female
4. Certerline :2.16mm(0.85 in)
5. Number of Position: 64 pin
6. Contact Material: Copper Alloy
7. Contact Plating: Gold (A:5u" ,B:10u",C:15u"A:30u'')
8. Comb Material:Thermoplastic
9. UL Flammability Rating: UL-94-V0
10. Shell: Stainless steel,Zinc plated,Tin ploted or Nickel plated steel
11. Orientation:Standard
12. Special Function:(Pan Holes)
A: Screw Lock B:Rivet Insert
C: 4.8mm Hex Screw Lock
D: IEEE488 Hex Screw Lock
3) Electrical Specifications
1. Current Rating: 5Amp
2. Voltage rating: DC 1000v per minute
3. Insulator Resistance: 1000Mn MIN.(at 500V DC)
4. Operation Temperature: -55°C to +105°C
5) Application
| 1, VDSL Telecom Equipment | |
| 2, Computer Peripherals | |
| 3, Communication Equipment | |
| 4, PCB Board | |
| 5, Cable to Panel | |
| 6, Cable to cable | |
| 7,Computer terminal | |
| 8,Telemetering | |
| 9,Test Equipment | |
| 10, Printer |
6) Technology Parameters
