Description:
Diode-Pumped Solid-state Lasers are ideal lasers that serve various and diverse industrial market segments.
Excellent beam quality, rock-solid stability, incredible efficiency and solid-state reliability make these lasers
the clear choice for application.
It integrates a Nd: YAG laser rod which is efficiently pumped by a radial array of long lifetime laser diode bars, and delivers excellent gain uniformity and lensing performance.
It is used for medium power multi-mode applications, precise micro-machining and scientific applications.
Specification:
Type |
DPL-1064-S3-0050- 04**-** |
DPL-1064-S3-0075- 04**-** |
DPL-1064-S3-0100- 04**-** |
Unit |
CW Output Power Po |
50 |
75 |
100 |
W |
Threshold Current Ith |
≤10 |
≤10 |
≤10 |
A |
Operating Current Io |
≤22 |
≤22 |
≤30 |
A |
Forward Voltage |
21±1.5 |
21±1.5 |
21±1.5 |
V |
YAG size |
Φ3*65 |
Φ3*65 |
Φ3*65 |
mm |
Weight |
≤1 |
≤1 |
≤1 |
kg |
CenterWavelength |
1064 |
nm |
||
Light Height |
40 or 45 |
mm |
||
Dope of YAG crystal |
0.8±0.1at% |
|
||
RecommendCase Temperature |
20±2 |
°C |
||
StorageTemperature Range |
-10~60 |
°C |
||
Mechanical Dimensions
1. This device is classified as a laser product of class IV, it emits high power invisible light. Please pay attention to the mark on this product, do not look directly at the laser output window (cross-section of the output beam);
2. Please do not expose output laser beam to a plane mirror or other reflective surfaces, reflected beam may make people injured or damage other objects;
3. The user should wear laser goggles;
4. If this product is used in the laboratory, there should be laser warning marks in this laboratory;
5. If the user wants to check the quality of laser spot, please use a wavelength converter or check attenuated laser spot with CCD;
6. If this product is not used in a super-clean room, DPL and its peripheral components should be
sealed to prevent power reducing due to blemish on crystal ends and surfaces of the cavity mirrors;
7. Avoid using this product in high humidity environment because it's easily to dew on the cavity surface
of the bar, do not run the chiller when DPL is not working; when beginning to use this product,
quickly supply current no less than 5A after turning on the chiller; quickly turn off the chiller after
stopping using this product;
8. To expel water, as from the water pipes outlet/inlet of the DPL module by washing ear ball or nitrogen gun when the DPL module not being used,the water pipes may splinter in low temperature.
Package: plywood packages
Shipping:
1. Door to door, by the DHL, EMS, UPS, FedEx etc.
2. by air to the Air cargo or by sea to the seaport.
1. 1 year warranty.
2. Professional technician support on all our products.
3. We supply the sample, user manual, video operation.
4. Online trade-manager 24 hours.
We will continue to “quality first, customer first” principle of service, to update, better product and Quality service to customers.
About us:
SINO-OPER just is growing friend with you, and always concentrates on innovative laser scanning Systems.
We are honored that our company is supported by the people who are working for it.
Reaching a goal requires a flexible, powerful, dynamic team that reacts on work together as one unit.
1. Minimum order quantity: 1 set
2. Payment terms: T/T in advance, western union
3. Delivery time: within 5 days after payment
4. Warranty: 1 year
