Automatic Digital Flatbed T Shirt Printer,digital T-shirt Printing Machine

Automatic Digital Flatbed T Shirt Printer,digital T-shirt Printing Machine thumbnail-1
Automatic Digital Flatbed T Shirt Printer,digital T-shirt Printing Machine photo-1
US$ 5,720 - 5,730 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Shenzhen Yueda Printing Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name yueda
Model Number YD-a2(4880)
Usage Other, T-shirt printer
Automatic Grade Automatic
Voltage 110-220V
Gross Power 75W
Dimensions(L*W*H) 1200*620*600mm
Weight 150KG
Certification CE
After-sales Service Provided Overseas third-party support available

Specifications

Specifications
1. can print 20 squs/h
2.high resolution 2880dpi *1440dpi
3.print size:420*850mm

automatic digital flatbed T shirt printer,digital t-shirt printing machine

Specifications

Yueda inkjet printer , it is the best technology for photo printing, and special for you to solve the following printing problems:







  • One piece printing can be acceptable, no plate-making, lower cost, suitable for the small quantity of products
  • Any materials can be printed. You can print Plastic, ABS, PVC, Metal, Glass, Textile etc with the same printer.
  • Multicolor printing, no chromatography needed, perfect color transition, brilliant printing results.
  • Good choice for the odd-shaped products, exquisite and multicolor printing results.



  • It accepts printable objects height up to 23cm.
  • It is very simple to operate this machine. Just normal workers can operate it well after brief training. You need only connect it with a computer, and then you can print out any picture from computer.
  • Instant image printing.
  • Low cost of printing image, less procedures of production.
  • Stable printing technology, it is good for numbered items or tailor made such as gift field.
  Applicable printing materials:


Plastics (ABS, PC, PE, PP, PU, PVC etc.), acrylic, metal, wooden articles, leather, glass, crystal, chrome paper, ceramic tile/chinaware, silica gel, stiff paper, wax, etc.

Application:
Electronic products, gifts, toys, personalized costume, house furnishings, chinaware, art work, fastener, crystal wares, advertising signage, leather goods, etc.







Basic parameters

  Print size: super A2Format largest printing range0.42mX0.85m
- Print head: 180 Nozzles 8 color, intelligent transformation of the
            Droplet   Technology.
- Print color: 8 color ( C+M+Y+K,LC,LM,LK,LLK)
- Max thickness of flat printing : 23cm
- Printing weight: Precision Nondestructive weight 100kg
- Max printing precision: 2880DPI * 1440DPI
- Ink tank volume: 220ML * 8color
- Printing speed A1 size: Around 5.0min (720 dpi * 360dpi/plain paper:
            Quality mode)
                          Around 7.2min (720 dpi * 360 dpi/coating paper: speed mode)
                          Around 9.9min (720 dpi * 720 dpi/coating paper: quality mode)
                          Around 14.3 min (1440 dpi * 720dpi/photo mode)
                          Around 26.9min ( 2880dpi * 1440dpi/high printing quality photo)
- Power requirement: 110-220V  50-60HZ  75W
- Printing interface: USB 2.0/1.1 interface and 100 Base -T  Ethernet interface
- Operation system: Window 95, 98, NT, 2000, XP, 2003 / MAC/Linux
- Net weight/ Gross weight : 150KG/ 200KG
- Printer size: 1.2m* 0.95m*0.6m

Features


This Yueda Universal printing machine of the integrative structure: Stable performance allowing limitless repetitive printing, complete registration without displacement, higher printing resolution.
Higher printing speed: More suitable for the batch production.
Printhead protector: Automatic induction function to adjust the height so as to protect the printheads.
Intellective spray nozzle monitoring unit: It automatically detects whether the printheads are blocked up or not and conducts the cleaning work automatically to ensure perfect printing effects.
Optimized ink supplying mode: It is unnecessary to reset the data on the main board, easy for maintenance to improve the work efficiency.
More reasonable structure makes it more convenient and fast to replace spare parts. Alloyed working table: lighter, higher stability and resolution.
USB2.0 high-speed interface and Ethernet interface of 10/100MB: It thoroughly resolves the data transmission problems of the printer to guarantee high-speed printing output and offer a perfect network printing solution.
Fashionable stream-lined outward appearance: Patented design with unique features.







Sampe


 automatic digital flatbed T shirt printer,digital t-shirt printing machineautomatic digital flatbed T shirt printer,digital t-shirt printing machineautomatic digital flatbed T shirt printer,digital t-shirt printing machineautomatic digital flatbed T shirt printer,digital t-shirt printing machineautomatic digital flatbed T shirt printer,digital t-shirt printing machineautomatic digital flatbed T shirt printer,digital t-shirt printing machine

automatic digital flatbed T shirt printer,digital t-shirt printing machineautomatic digital flatbed T shirt printer,digital t-shirt printing machineautomatic digital flatbed T shirt printer,digital t-shirt printing machine

Dear customers:
        Welcome to my shop.here you can know the most popular flatbed printer&UV printer on the  market nowadays. hope you shopping happy here. any more interest or questions you can contact me directly.

Thanks/ sheena

sheena Yang    0086-15012620343

sheena @ yd1688. com

skype:sheena.Yang12
