Help CenterScan Head for the CO2 Fractional Medical Equipment
Related Products
-
CO2 Fractional Galvonometer ScannerNegotiableMOQ: 1 Set -
RF CO2 Laser Treatment MachineNegotiableMOQ: 1 Unit
-
Beauty Galvonometer ScannerNegotiableMOQ: 1 Set
-
Scar Removal CO2 Fractional System/machineNegotiableMOQ: 1 Set
-
CO2 Fractional Machine for Skin Renewing and ResurfacingNegotiableMOQ: 1 Set
Specifications
1.high speed and high stable2.Long work time
3.High precision
scan head for the CO2 fractional beauty equipment
Application:
The galvo scanner is the new generation of the medical and beauty galvanometer system
which is mainly used in the fractional laser system. We adopt the newest technology in
the produce which is high speed and stable.
Specification:
Specification for motor
Working Temperature |
25°C ± 20°C |
Linearity |
99.9% |
Setting Time |
≤ 0.23ms |
Scale Drift |
< 20PPM/°C |
Zero Drift |
< 10μRad. /°C |
Long Term Drift Over 8 hours |
< 0.5mRad |
RMS Current |
3A(Max) |
Peak Current |
15A(Max) |
Maximum Scan Angle |
± 20° |
Storage Temperature |
-10 to +60°C |
Resolution |
8μrad |
Repeatability |
12μrad |
Input Aperture |
3~7mm |
Frequency |
≤1400Hz |
Specification for driver
Input Voltage |
± 15/24VDC@4A MAX.RMS |
Interface Signals |
Digital:XY2-100 |
Analog Signal Input Resistance |
200K ± 1%Ω |
Position Signal Input Resistance |
1K ± 1%Ω |
Position Signal Input Scale Factor |
0.5V/° |
Position Signal Output Scale Factor |
0.5V/° |
Working temperature |
0°C - 40°C |
Packing:
scan head for the CO2 fractional beauty equipment will be packed in the wooden case or carton case.
Shipping:
1.Door to door, by the DHL,EMS, UPS,FedEx etc.
2.By air to the Air cargo or by sea to the seaport.
1. 1 year warranty.
2. Professional technician support on all our products.
3. We supply the sample,user manual, video operation.
4. Online trade-manager 24 hours.
we will continue to “quality first,customer first” principle of service, to update ,better product and quality service to customers.
About us:
SINO-OPER just is a growing friend with you, and always concentrates on innovative laser scanning systems.
We are honored that our company is supported by the people who are working for it.
Reaching a goal requires a flexible, powerful, dynamic team that reacts on work together as one unit.
Contact us:
grace.cao65
grace.c AT m
+86-010-82790570 +86-18810824815
1.Minimum order quantity:1set
2.Payment terms: T/T in advance, western union
3.Delivery time: within 5 days after payment
4.Warranty: 1year
