Home > Lights & Lighting > LED Interior Lighting > LED Panel Light > 9W Panel High Power LED Light 3X3W LED Light Panel
9W Panel High Power LED Light 3X3W LED Light Panel
US$ 5 - 8
MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
High Power LED
Warranty(Years):
3
Input Voltage(V):
AC85-265V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Wholesales China Manufacturer for 25W LED Light Panel With High Power LEDUS$ 10 - 15MOQ: 100 Pieces -
ShenZhen 9W Led Panel Light 9watt 3*3 Distribute LED Panel LightUS$ 5.1 - 5.25MOQ: 100 Pieces
-
ShenZhen Surface Led Panel Light 6w Ceiling Mounted LED Light Panel LightUS$ 2.08 - 2.25MOQ: 100 Pieces
-
ShenZhen LED Light Factory Panel Light 18w Square LED Panel Light HousingUS$ 6.08 - 6.5MOQ: 100 Pieces
-
LED Light Panel Light 12w LED Flat Panel Light Eyeshield SMD2835 85-265V LED Panel LightUS$ 4.85 - 5.15MOQ: 100 Pieces
LED Light Source
High Power LED
Warranty(Years)
3
Input Voltage(V)
AC85-265V
Lamp Power(W)
9
Lamp Luminous Flux(lm)
760-810
Lamp Luminous Efficiency(lm/w)
90
Color Temperature(CCT)
Warm White
Working Temperature(℃)
-40, +55
Working Lifetime(Hour)
35000
Lamp Body Material
Aluminum
IP Rating
Other, IP20
Certification
CCC, CE, EMC, FCC, LVD
Place of Origin
Guangdong, China
Brand Name
SOUTEC LIGHTING
Model Number
FG-PNH1P09A-6
9W Panel High Power LED Light 3X3W LED Light Panel
Advantages
1. Experienced technical staff
2. Advanced equipment
3. High quality
4. Experienced R&D department
5. OEM accepted
6. Strong production capability
7. Large scale production lines
8. Clients' special requirement accepted
9. Unique design
10. Good reputation
Product Description
LED panel Light is kind of lighting products embedded into the ceiling,LED panel Light belongs to the directional lighting,only its face direction can light,its light beam is focus,bright and dark areas is clear.
The feature of LED panel Light:It is perfectly embedded into the ceiling,do not influence the appearance of
ceiling.
***Energy saving: power consumption is 1/2 of CFL
***Environment friendly:No mercury etc metal material,no pollution to the environment
***Economic:Saving power and saving money
***Super long lifetime.
Since 2012,more and more offices even if home fix with LED panel Light.The performance of led down light is accepted by the users gradually.Led Down Light owns some advantages that other led lights can not have.
1,LED panel Lights do not occupy the space
2,The base of LED panel lights are installed inside of the roofs,can have a comfortable feelings.
3,LED panel Lights are widely used in super markets,office,factory,hospital etc,install easily.
4,LED panel light not only have the advantages of traditional panel lights,but also with the features of lower heat,energy saving,super long lifetime,lower maintenance cost.Two years ago,because of the high cost of LED makes the cost of led down lights much higher,most of the clients can not accept,but now it goes down a lot,the cost is acceptable for the clients.Under the development of the LED Technology,the cost of led and all other components go down continually,all these make the base of large use for commercial lighting.
5,LED panel Light can beautify the house,and do not break the set of the led hang lamps;All the lights body sealed into the roof,and the surface of the down lights is flat with roof,the light is no dazzle,soft and even.
6,Economic,it can saves 1/2 power comparing with common CFL,it can save the cost of power consumption
7,LED panel light is not easy fragile, and environment and can be recycle,no mercury,and no pollution to the environment.Less energy consumption, reduce the carbons dioxide emissions.
8,Super long tife time,if one day use 6 hours,can use about 15 years,reduce the cost of lighting.
Cautions of using LED panel Light
1,Open the package,and check if the led panel light is broken or not.
2,Turn off the power supply before fix to prevent electricity shock,after the led down light is fixed well,turn on the light,but please do not touch the surface of the led down light.Please do not fix led down light to close to the heat goods,or heat air,or corrosive gas to prevent reduce the lifetime of the led down lights.
3,Before use,please confirm the quantity and the power supply.The led down light is used indoor only,if you use for outdoor,please make the waterproof equipment,and make sure that the installation site can take about 10 times weight of the products.
4,Products are 85~265VAC input,not suitable for frequent on/off,in addition,if you need DC12V,we also can make.
5,Fix on the place no shake,no fire,in addition,avoid to drop down,knock with strong goods.
6,If you use it for long time,please keep the environment for store cool,dry and clean,not allowed to store or use in the moist,high temperature or explosive environment.
Specification
Model No |
FG-PNH1P09A-6 |
Input voltage |
85-265VAC/220VAC/110VAC 50hz/60hz |
Power(watt) |
9W |
Product size(mm) |
150*150MM |
Color temperature |
2800~3300K/4000~4500K /6000~6500K |
LED Chip |
Cree/Epistar/Samsung/San’an |
Mount hole size |
135*135MM |
Housing Color |
white |
Luminous Flux (lm) |
760-810Lm |
CRI(Ra) |
75 |
Lifespan |
≥35000hrs(Energy star standard) |
Beam Angle |
120° |
Material |
Aluminum housing+PC Cover |
Operating Temperature |
-40℃ – +55°C |
Dimmable |
Optional |
PF |
>0.5 or >0.9 |
IP |
IP20 |
Certificate |
CE,RoHS |
Package size |
370*245*360mm 20pcs/carton |
Product Overviews
Color Temperature
Installation
Application
Application range:
MINI LED Panel light is widely used to replace the grill lamps,the main application is showed as follows:
1, Roof
2,Wall
3,Installation body
4,Others(Such as train and counter)
