High Quality EMC Ip67 100W 3.0A Led Waterproof Power Supply
Negotiable
MOQ: 500 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Evada
Model Number:
CHF-100-300-FA2
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
350ma ac dc Power Supply Led Driver 100wNegotiableMOQ: 500 Units -
Ip67 Enclosures 120w Electronic TransformerNegotiableMOQ: 500 Units
-
ce Approved 48v Power Supply, 200w Led DriverNegotiableMOQ: 500 Units
-
Power Supply 200w High Voltage dc Power Supply 42v Power AdapterNegotiableMOQ: 500 Units
-
3 Years Warranty 24v Constant Voltage Led Driver 200w Led DriverNegotiableMOQ: 500 Units
Place of Origin
Fujian, China
Brand Name
Evada
Model Number
CHF-100-300-FA2
Output Power
Other, 100W
Output Type
Single
Input Voltage
Other, 176-264V AC
Output Voltage
33VDC
Output Frequency
50Hz/60Hz
Output Current
3.0A
Product Description
High quality EMC ip67 100W 3.0A led waterproof power supply
Features :
| 1. Universal AC input / Full range (up to 264VAC) |
| 2. Protections: Short circuit / Overload / Over voltage |
| 3. Built-in active PFC function |
| 4. Cooling by free air convection |
| 5. Suitable for LED lighting and moving sign applications |
| 6. IP65 / IP67 design for indoor or outdoor installations |
| 7. Damp / wet location outdoor application |
| 8. Compliance to worldwide safety regulations for lighting |
| 9. 3 years warranty |
| 10. OEM service. Ouptput current/wattage etc. are customizable |
Specification
| MODEL | CHF-100-300-FA2 | |||||||||
| OUTPUT | DC VOLTAGE | 33V | ||||||||
| CONSTANT CURRENT REGION | 33VDC | |||||||||
| RATED CURRENT | 3.0A | |||||||||
| RATED POWER | 100W | |||||||||
| RIPPLE & NOISE (max.) | 1.2Vp-p | |||||||||
| LINE REGULATION | ±3% | |||||||||
| LOAD REGULATION | ±3% | |||||||||
| SETUP, RISE TIME | 3000ms, 600ms at full load 230VAC | |||||||||
| HOLD UP TIME (Typ.) | 50ms / 230VAC at full load | |||||||||
| INPUT | VOLTAGE RANGE | 176-264VAC | ||||||||
| FREQUENCY RANGE | 47-63Hz | |||||||||
| POWER FACTOR | PF≥0.95/230VAC | |||||||||
| EFFICIENCY (Typ.230Vac/50Hz) | ≥89% | |||||||||
| AC CURRENT | 0.68A / 230VAC | |||||||||
| INRUSH CURRENT(max.) | COLD START 5A/230VAC | |||||||||
| LEAKAGE CURRENT | <5mA / 240VAC | |||||||||
| PROTECTION | OVER CURRENT (Typ.) | 95 - 108% | ||||||||
| Protection type : Constant current limiting, recovers automatically after fault condition is removed | ||||||||||
| SHORT CIRCUIT | Hiccup mode, recovers automatically after fault condition is removed | |||||||||
| OVER VOLTAGE | 27V-30V | |||||||||
| Protection type : Constant voltage limiting | ||||||||||
| ENVIRONMENT | WORKING TEMP. | -30 ~ +55℃ @ full load ; +70℃ @ 60% load | ||||||||
| WORKING HUMIDITY | 20-95% RH non-condensing | |||||||||
| STORAGE TEMP., HUMIDITY | -40~ +80℃, 10 ~95% RH | |||||||||
| TEMP. COEFFICIENT | ±0.03%/℃(0-50℃) | |||||||||
| VIBRATION | 10 - 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes | |||||||||
| SAFETY & EMC | SAFETY STANDARDS | UL1012 ; EN61347-1, EN61347-2-13 independent ; UL60950-1, TUV EN60950-1 (TBD) | ||||||||
| WITHSTAND VOLTAGE | I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC | |||||||||
| SOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 ℃/ 70% RH | |||||||||
| EMI CONDUCTION & RADIATION | ||||||||||
| HARMONIC CURRENT | Compliance to EN61000-3-2 Class C (≥75% load) ; EN61000-3-3 | |||||||||
| EMS IMMUNITY | Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN61547, EN55024, light industry level (surge 4KV), criteria A | |||||||||
| OTHERS | MTBF | 30Khours. | ||||||||
| DIMENSION | L145*W69*H39.2mm | |||||||||
| NOTE | 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. | |||||||||
| 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. | ||||||||||
| 3. Constant current operation region is within 75% ~100% rated output voltage. This is the suitable operation region for LED related applications, but please reconfirm special electrical requirements for some specific system design. | ||||||||||
| 4. Safety and EMC design refer to EN60598-1, subject 8750(UL), CNS15233, GB7000.1, FCC part18. | ||||||||||
waterproof led power supply
Mechanical Specification
Series Recommend
Packaging & Shipping
High quality EMC ip67 100W 3.0A led waterproof power supply
