Help CenterDJM-300-1P High Quality Of Electric Shutter Motor
Related Products
-
DJM-300-1P Electric Rolling Door Motor(100% Test)US$ 60 - 200MOQ: 100 Sets -
DJM-300KG-1P Electric Engine Motor for Rolling Shutter Door Quality ChoiceUS$ 1 - 249MOQ: 100 Sets
-
DJM-300-1P Side Mounting Automatic Door OpenerUS$ 1 - 249MOQ: 1 Set
-
DJM-300-1P Side Chain Rolling Door Motor(Easy Installation and Operation)US$ 1 - 249MOQ: 1 Set
-
DJM-300-1P Side Chain Rolling Door MotorUS$ 1 - 249MOQ: 1 Set
Shutter motor Specifications
Electric shutter motor:
1.Certificate: CE,ISO9001
2.OEM: Offered
3.Low noise
4.safe&stable
Shutter motor Description
Before using/buying electric shutter motor,please read first:
- Left or right installation is ok
- design controller with different funtions according to customers request.
- 300kgs/500kgs could add reserve power function
- overheat protection:if the motor temperature is over 110 degreed centigrade, the motor stops working automatically, works again if temperature return below 70 degreed centigrade
- It can be operated by electricity and manual
- Durable compact design great elevating power with low noise
- Could match infrared sensor or alarm system(optional)
- Four relays inside the motor,four micro-active switch inside the limit system
Company Information
Our factory has been committed to product technology research and product continuous improvement, Our products include: Rolling door motors, Electronic motors, Aluminum casting, Aluminum alloy/Zinc alloy die casting products and machined items. We are sure we can make a good manufacture for you.and welcome to visit our company.
1) manufacture AC, DC, AC and DC roller shutter door motor
2)AC motor: 150KG—1300KG, AC and DC motor: 300KG—600KG
3)100% copper material inside the motor, so it have a larger capacity and durable than other motors
4)make dimension of bracket system according to your request, brake system build in the bracket system
professional company and professional sales makes your reliable supplier in China.
Advantages of our Electric shutter motor
1.Professional and automatic manufacturer and products are manufactured according to specification
2.Small dimension that will not occupy space. It is lightweight as the entire outer shell is made by aluminum alloy. Not only it as a beautiful cosmetic appearance, it can also be installed easily.
3.Each Rolling door motor needs to be tested for loading and durability before packing and delivery.
4.Our quality control inspection from production of every single component to assembly is entirely performed and each part of the process has its own severe regulation and standard to comply with.
Electric shutter motor technical datas
| Model | Motor Power(W) | Max.lifting force(KG) | Max.hosting height(M) | Max.output Torque(N.W) | Rated Current(A) | Large Sprocket Reel Speed(R/MIN) | Chain No. |
| Power Supply(V/HZ): 220/50 | |||||||
| DJM-300-1P | 250 | 300 | 6 | 168 | 3.3 | 4.8 | 08B |
| DJM-400-1P | 250 | 400 | 6 | 225 | 3.3 | 4.8 | 08B |
| DJM-500-1P | 370 | 500 | 6 | 343 | 3.9 | 4.8 | 10A |
| DJM-600-1P | 370 | 600 | 6 | 412 | 3.9 | 4.8 | 10A |
| DJM-800-1P | 400 | 800 | 9 | 647 | 4.5 | 3.94 | 10A |
| DJM-1000-1P | 400 | 1000 | 9 | 809 | 4.5 | 3.75 | 12A |
| Power Supply(V/HZ): 380/50 | |||||||
| DJM-600-3P | 250 | 600 | 6 | 412 | 1.2 | 4 | 10A |
| DJM-800-3P | 300 | 800 | 9 | 647 | 2.0 | 3.94 | 10A |
| DJM-1000-3P | 400 | 1000 | 9 | 1102 | 2.3 | 3.74 | 12A |
| DJM-1300-3P | 600 | 1300 | 9 | 1372 | 3.0 | 4.4 | 12A |
| DJM-1500-3P | 600 | 1500 | 9 | 1610 | 3.2 | 5.2 | 16A |
High quality |
100% copper wire |
CERTIFICATIONS |
CE,ISO9001 |
OEM |
YES |
WARRANTY |
1 year from the day of shipment |
AC MOTOR INCLUDE |
motor part, assembly bracket, remote control sets, flange & rings, metal key box. |
AC MOTOR LOAD CAPACITY |
450-500 SETS FOR ONE 20GP CONTAINER. |
MOTOR PACKAGE |
TWO CARTONS WITH FOAM INSIDE , ONE FOR MOTOR, ONE FOR BRACKET |
About us
Shutter motor detail
Our Services
Main products: AC electric rolling door motor/rolling shutter motor/side rolling door motor/chain drive rolling door motor/gear rolling door motor,AC/DC rolling door motor,remote controller,Swing gate operators, tubular motors,garage door opener.
Warranty time : 1 year warranty from the date of shipment.
Delivery time: 20-30 days after receive the deposit. (depends on the order quantity)
Contact Person: Maggie Fang 0086-13850001209/0086-18030113078
Production Line of shutter motors
CE certificate
ISO9001
FAQ
Electric motor trouble shooting:
