YD-1825 High Definition Large Format Digital Printed Wall Tile

YD-1825 High Definition Large Format Digital Printed Wall Tile photo-1
US$ 30,800 - 30,900 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name Yueda
Model Number yd-1825 digital printed wall tile
Usage Paper Printer, Label Printer, Card Printer, Tube Printer, Bill Printer, Cloths Printer
Automatic Grade Automatic
Voltage 110-220V 50*60HZ
Gross Power 75W
Dimensions(L*W*H) 3500*2700*1500mm
Weight 600KGS
Certification CE, SGS
After-sales Service Provided Overseas service center available

Specifications

YD-1825 high definition large format digital printed wall tile
CISS
Resist of sunshine
One year warranty

YD-1825 high definition large format digital printed wall tile

A. Specification  Betty   Tel: 86-13691707201   Skype: smilebetty12
Print size1800mm*2500mm
Print headEpson DX5 Printhead 180Nozzles×8Color,Drops controlled micro piezo print technology
Print colorDouble 4color/ 4color(CMYK),Double 8color/8color
Max thickness of flat printing 10cm
Printing weightPrecision Nondestructive Weight 100kg
Printing precision2880*1440dpi/32Pass,1440*1440dpi/16Pass,1440*720dpi/8Pass,720*720dpi/4Pass,720*360dpi/2Pass
Lifting functionIntelligent Printhead Up and Down
Software formatTIFF(RGB&CMYK),BMP,PDF,EPS,JPEG and so on
Ink tank volume1L×4Color / 220ML×8Color,CISS
PrintHead quantity Double Head
Printing speed CMYK+4W2*CMYK
720*720dpi/4Pass 17m2/h720*720dpi/4Pass 28m2/h
1440*720dpi/8Pass 10m2/h1440*720dpi/8Pass 19m2/h
1440*1440dpi/16Pass 4.5m2/h1440*1440dpi/16Pass 9.5m2/h
2880*1440dpi/32Pass 2.5m2/h2880*1440dpi/32Pass 5m2/h
Power requirementAC220/110±10,50HZ~60HZ,1500W
Printing interfaceHigh-speed USB2.0/USB3.0
Operation systemMicrosoft Windows98/Me /2000 /XP/Win7
Software outputPhotoprint RIP,Maintop RIP (Windows 2000,Windows XP Pro Sp2)
Operation environmentTemperature 15-35C,Humidity 20-80RH
Printer weight1800KG(N.W)
Printer size3.2m x2.8m x1.4m



B. Feature

1.Any flat materials can be printed.



2.No plate-making, lower cost, suitable for the small quantity.



3.Brand new structure and design, new visual enjoyment, more reasonable spatial arrangement, more convenient operation



4.Newly developed yinghe unique three-optical-fiber high speed data transmission system, stronger anti-jamming capability, more stable and reliable system.



C. Advantages

1. No plate-making, fast printing, low cost, available for the output of various of software;



2. Changing color directly by the computer, changing color wherever, no need to pay the extra fees;



3. Could meet the requirements of fast getting the sample or products even in some seconds;



4. Could print at unit price, printing in mass production, going with template matching, time saving;


5. Full color photos, finish once, progressive color could meet the image results of quality;



6. Handled with fast, quality production, no need to get professional skills;



7. Computer operation, no need to depend on the stuff with a lot of upgrade space.

D. Business Condition

1. Terms: FOB Shenzhen



2. Payment: T/T 30% deposit, 70% balance payment before shipment.



3. Delivery Time: about 3days after receiving the payment.





A set of ink and a bottle of machine cleaner are be sent free!!!



We're professional flatbed printer manufacturer, and we can do OEM and ODM as customers' required, WELCOME to turn to us for more information !

YD-1825 high definition large format digital printed wall tileYD-1825 high definition large format digital printed wall tile

YD-1825 high definition large format digital printed wall tileYD-1825 high definition large format digital printed wall tileYD-1825 high definition large format digital printed wall tile
