Specifications
digital inkjet ceramic tiles printer1.for any flat materials
2.Low cost,chage color directly.
3.operation control by comput
UV digital inkjet ceramic tiles printer with double DX7 Printhead
Model |
Multifunction Printer YD-6090uv |
Print size |
600*900mm |
Print Technology |
LEDUV curing; intelligent bi-directional printing; automatic nozzle detection; automatic head cleaning; transform Droplet. |
Print color |
Double 4color/ 4color(CMYK),Double 8color/8color |
Max thickness of flat printing |
90mm |
Printer speed |
720*720dpi/4Pass 25m2/h |
1440*720dpi/8Pass 17m2/h | |
1440*1440dpi/16Pass 8m2/h | |
Printing weight |
Precision Nondestructive weight 100KG |
Software format |
TIFF(RGB&CMYK),BMP,PDF,EPS,JPEG etc. |
Head safe |
IntelligentLevel 3 anti-collision function |
Max printing precision |
2880DPI*1440DPI |
Height control |
Printer head go up and down |
Printer head protection |
Intelligent Touch type testing automatic protection system technology |
Power requirement |
110-220V 50-60HZ 75W |
Printing interface |
USB2.0/1.1 interface and 100 Base-T Ethernet interface |
Operation System |
Window95,98.NT.2000.XP,2003/MAC/Linux windows 7 |
Working environment |
optimal temperature: 20 °C -30 °C, relative humidity of 40% -70% |
Printer weight |
650kg |
Printer size (L*W*H) |
1.5m x1.0m x1.4m |
Shenzhen Yueda Printer technology co,.Ltd is a factory that contain the R&d, design, Production, sales. It is a pioneer in the product and the R&d Multifunction Printer of china. Our company have accumulated many experience in the multi-funtion Industry Sector. Based on the technical support platform of some Well-known manufacturers as EPSON, INTEL and so on. now our company have successful development the models including from , A3, A3+, A2, A2+, A1, A0, etc all series type. The models is the best in the china. Digital Flatbed Printer is a new product in printing industry, it can print on the surface for various kinds of flat objects directly, such as metal, glass, leather, wood, bamboo, cloth, t-shirt, plastic, silica gel, high-density plank, PVC, acrylic, advertising materials. Multifunction Printer can satisfy the requirement of many industry output high quality image.
1. About us?
We are one of the true manufacturer of printer, located at Shenzhen. About 2 minutes to Jixiang subway.
2. About price and quality?
We can not say we are the best supplier, but we are honesty for our quality and price. Good quality is our first rule, and good service is our mission. We produce machines as 5S management rules, and ISO standard.
3. Why you choose our factory?
We produce flatbed printing machine, digital flatbed printer is a new product in printing industry, it can print on the surface for various kinds of flat objects directly, such as crystal, leather, glass, metal, ceramic tile, PVC, PP, PE and so on. Any pictures can be printed on the surface of the subjects by the printer with high resolution ,it is the fastest flatbed printer on the current market. And we will keep you with a best service, give us a chance, also give your a chance to know this field if you really want to know this printer.
4. What is the printer operation?
1. Through a digital camera or scanner to get File sources of pictures
2. Through the computer images to typesetting modified document layout
3. Through the universal printer output files to print.
4. Print objects requirements (any flat object, no influence print on any mate)
sample show :
advantages:
By part of printer: | ||
Motor |
Taiwan teco servo motor, high accuracy and stable printing,nationwide quality assurance. |
|
Mute guide rail |
Taiwan slide rail and double slider of silver, high precision, low noise, wear resistance,Guarantee the stability and accuracy of sprinkler car moving. |
|
Ink car lift up and down |
Taiwan's precision of silver double screw, ensure the nozzle lift precision and stability of the head, belt scale. |
|
Synchronous wheel synchronous belt |
America gates synchronous belt wheel, ensure the operation stability and accuracy of printhead protection, belt scale. |
|
Head |
Japan's original EPSON DX5 - head reflection protection head |
|
Photoelectric switch |
Japan omron photoelectric switch |
|
Switch, indicator light |
Germany's Siemens and schneider |
|
Vacuum adsorption device |
High power double vortex blower, independent zone control |
|
platform |
High precision suction platform, the surface hardening treatment, not easy scratches, absorb UV light does not reflect printhead protection, platform with size scale. |
|
UV Light |
The United States imported LED water cooled UV light, service life of 60000 hours |
|
Bearing |
The Swedish SKF imported bearing, to guarantee the machine precision |
|
Tanks towline |
IGUS Germany IGUS mute drag chain, low noise, high life. |
|
Auxiliary function |
With simple computer desk |
|
After-sales service and solutions: | ||
Warranty: |
one year warranty , maintenance for life |
|
Special coating |
Glass coating, metal coating, leather coating, ceramic coating, etc |
|
Ink |
High quality UV ink, dedicated to prevent clogging |
|
Technicanl Support |
The entire phone 24 hours tracking and professional technical guidance |
For Free |
Work Shop/place construction |
Planning design, professional engineers to provide guidance |
For Free |
Operator training |
Training operator can skilled work instruction at customer side. |
For Free |
