Digital mass production roll textile bed sheet machine, digital roll nylon printer with high speed
Tips
Below is our factory video,pls check it,if you think this is best for you,pls contact Alia.whatsapp/wechat: 0086 13925228627
Website:
skype: alia_printer
1.8 pieces SG1024 industrial level stainless steel printheads:the industrial level printheads are widely used by digtial printing factory in Europe.Suitable for continuous,batch printing and continuous printing production;
Feature
SG1024 Printhead;
2.Width 1.8m,2.6m and 3.2m optional:suitable for printing clothe and home textile field with different width requirements;
3.Professional conduction band of fabric conveyor system:it can transfer the cloth without tension,suitable for spandex and Non-elastic cloth;
4.Original automatic wiper system,its not hurt the nozzle;
5.Conduction band automaticly washing and drying system;
6.Conduction correction system;
7.Media and retraction system,automatic constent tension Unwinding and rewinding system,wrinkle technology is high-efficiency and stable;
8.Drying system:Multiple wave infrared heaters,instant drying cloth,adopts printing and drying,linkage control mode,high-effiency and stable,easy operation,Independent drying system optional.
Specification
Specification | |
| Printer model | YD1800- SE |
| Output Speed | 120 square meters/h(3 PASS) |
| Print Width | 1.8m(width) |
| Fabric Thickness | Adjustable height range 0-30mm |
| Printhead | SG 1024 printhead,with own heating and internal-loop function |
| Print Resolution | 400dpi |
| Print Height | 30mm |
| Print speed | High-speed mode 3pass-120sqm/h;Normal mode 6pass-100Sqm/h;High resolution mode 8pass-60sqm/h |
| RIP Software | Professional textile printing RIP software |
| File Format | JPEGTIFFBMP(File Format) |
| Applicable fabric | All kind of cotton, hemp, silk, nylon, polyester and other woven and knitted fabrics, etc |
| Ink Color | Ten colors optional:Cyan, magenta, yellow, black, light cyan, light magenta, sapphire blue, orange, red, gray |
| Ink Type | Acid, reactive, disperse, paints |
| Printer size | 4300*1900*1900mm Weight:2500KG |
| Power | 25KW |
| Power supply | 380VAC ± 5%,three-phase five-wire, 50HZ ± 2% |
| Compressed air | air flow ≥0.6m³ / min, pressure ≥8kg |
| Working environment | the optimum temperature:20℃-30℃,Relative humidity 50%-80% |
Samples show
A leading manufacturer of UV based printers in the world since 2001. Head company in HongKong – YUEDA INTERNATIONAL (HONGKONG) INDUSTRY CO., LIMITED has been successfully able to sell more than 50 countries. The company has the necessary experience and the in house expertise to support printing applications in varied industry segments like Glass, Ceramic tiles , Glass,Wood, ACP, Signage, etc.
Our customers
Certificate
We are looking for agents now. no matter where are you from,
welcome to join us, pls contact Alia:
Skype:alia_printer
whatsapp/wechat: 0086 13925228627
Website:
