9 CBM 6*4 Concrete Mixer Truck HOWO Chassis

Name: 9 CBM 6*4 Concrete Mixer Truck HOWO Chassis
Brand: Xinxing
SKU: 113471967

US$ 57,000 - 58,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

China

Brand Name:

Xinxing

Qingdao Xinxing Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin China

Brand Name Xinxing

Model Number XX6520GJB

Weight 25t

Dimension(L*W*H) 9050*2496*3750

Power(W) 380HO

Certification ISO9001&CCC

Warranty 12months

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.10 years export experience
2.strong tanker body
3.ISO9001 ,CCC
4.Italy pump,motor and hydraulic
5.We are Manufacturer

9m³ 6*4 concrete mixer truck HOWO chassis

Model			9m³
Mixer truck performance and parameter		Chassis	HOWO
		Curb weight	13500
		Total mass of truck	25000
		LBH (mm) Mixer truck dimensions	905024963750
		Wheel base	3825+1350
		Front overhang	1500
		Rear overhang	2375
		(mm) Min. ground clearance	314
		speed	90
		Min. turning diameter	≤19.6
		Oil consumption/100km:(L)(Limiters)	34
Truck configuration		Clutch	φ430 Monolithic dry type
		Transmission	HW18709 Sinotruk
		Drive style	6*4
		Steering mechanism	ZF8098
		Service braking	Double-circuit pneumatic brake
		Parking braking	Spring stored energy air cut brake
		Auxiliary braking	Engine exhaust braking
Engine parameters		Type	water-cooled after-cooling EFI diesel/direct injection diesel
		Number of cylinders and arrangement	In-line six-cylinder
		Maximum torque	1350(1300-1600)N.m
Mixing drum parameters		(m3) Mixing drum geometric volume	14.7
		(m3) Max. mixing volume	9
		(°) Mixing drum inclination	13.5
		m³/min Feed speed	≥3.5
		m³/min Discharging speed	≥3
		Residual rate	Almost zero
		(m3) rotating speed	0-14
		(mm) Max. diameter of mixing drum	φ2162
Driving system		Reducer	ITALY BONFIGLIOL
		Hydraulic pump	AMERICA EATON
		Hydraulic motor	AMERICA EATON
		Radiator	with vacuum meter
Water supply system	Water tank volume		260/300
Water supply system	Way of water supply		Water pump pumping; Air pressure pumping
