2016 famous electromotor concrete pump in china
- 12 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Power Type: | Electric | Place of Origin: | Shandong, China |
Brand Name: | CONELE | Model Number: | HBT60S-13/HBT80S-16 | Power(W): | 90Kw |
Weight: | 5000Kg | Dimension(L*W*H): | 125/80*1650 | Certification: | CE&ISO9001 |
Warranty: | 12months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Item | Unit | |||||
HBT60S-13 | HBT60S-16 | HBT80S-13 | HBT80S-16 | |||
Theoretical concrete conveying amount | Low pressure | m3/h | 60 | 60 | 80 | 80 |
High pressure | m3/h | 36 | 35 | 47 | 46 | |
Theoretical concrete conveying pressure | Low pressure | Mpa | 7.6 | 9.6 | 7.6 | 9.6 |
High pressure | Mpa | 12.5 | 15.7 | 12.5 | 15.7 | |
Distributor valve type | S-valve | S-valve | S-valve | S-valve | ||
Hydraulic system pressure | Mpa | 32 | 32 | 32 | 32 | |
Motor speed | r/min | 1480 | ||||
Main oil pump | Imported German HAWE / Japanese Kwasaki with original packing | |||||
Main oil cylinder diameter | mm | 125/80x1650 | 140/90x1650 | 125/80x1650(1800) | 140/90x1650(1800) | |
Conveying cylinder diameter | mm | 200 | ||||
Motor power | Kw | 90 | 110 | 110 | 132 | |
Hydraulic oil tank capacity | L | 500 | ||||
Bucket capacity | m³ | 0.6 | ||||
Work voltage | V | |||||
Whole machine weight | kg | 5000 | 5200 | 5200 | 5500 | |
Maximum conveying distance | Vertical | m | 180 | 250 | 180 | 250 |
Horizontal | m | 700 | 1000 | 700 | 1000 | |
Packaging Detail: Containers Waterproofing packing Corrosion resistant packing Reinforcement packaging
Delivery Detail: 15- 25 DAYS
Our products are saled all over the country's 34 provinces, cities and autonomous regions, and have exported to more than 30 countries and regions around the world.
Receive maintenance call——Call guidance or send engineer to solve on the spot——If need change some parts———Within the guarantee time change the parts without charging/Without the guarantee time provide the parts with the favourable price
Within the guarantee time send the parts to the door without charging.
Without the guarantee time, provide lifelong charging service and favourable price parts.
1. Top ten construction machinery manufacturers in China.
2. A company with more than 20 years' professional experience.
3. Professional teamwork of every process.
4. Competitive priceand good CE&ISO9001 quality.
5. Efficient after-sale service.
