SX823 pH/mV/conductivity/TDS/salinity/resistivity digital ph meter price
USD $370 - $390
/ Set
1 Set(Min.Order)
- 25 Set / Sets per Month
- shanghai
- Credit Card PayPal
You May Like
- HC-B090 Laboratory PH meter
- Dual inline ro water purifier tds monitoring tds conductivity monitor for RO water treatment system with 2 probes
- water quality testing instruments water conductivity test meter detection TDS sensor probe TDS probe line
- OEM Analog TDS probe Module waterproof Total Dissolved Solids Water quality detection conductivity tds sensor
- 2 in 1 Type Titanium Alloy Water Temperature Detection Probe Line Precise Measurement Quick Connection Conductivity Test Pen TDS
- 3/8 inch 3 in 1 IC sensor water quality detector tds water conductivity test probe with CPU computing module for water filter
Product Details
Place of Origin: | Shanghai, China | Brand Name: | YANHE | Model Number: | SX823 |
Product Description
Measurement of parameters such as pH, mV, conductivity, TDS, salinity, resistivity and temperature of water solution, the most cost effective portable analytical instrument.
Double-parameter meter, equipped with pH electrode and conductivity electrode, automatic identification of electrode by meter. |
The meter is able to recognize up to 12 types of pH standard buffer solutions. There are three options of standard buffer solutions: USA series, NIST series and Chinese series (CH), there is also customer-defined solution calibration. |
The meter provides two special modes for pure water and pure water mixed with ammonia. These special modes offer temperature compensation for pH value, especially suitable for the electricity and petrochemical industries. |
The meter is able to switch among conductivity, TDS, salinity and resistivity measurement mode. For TDS measurement, the coefficient is adjustable. |
The meter is able to recognize up to 8 types of conductivity standard solutions. There are two options of standard buffer solutions: USA series and Chinese series (CH), there is also customer-defined solution calibration. |
The meter has an automatic range feature with automatic non-linear temperature compensation for pure water and high purity water with conductivity values lower than 10uS/cm greatly improving accuracy and suitable for the electricity, microelectronics and pharmaceutical industries. |
Equipped with calibration solution and portable case and suited in field and on site. |
Meter meets IP57 rating. |
pH | Range | (-2.00 ~ 19.99)pH |
Resolution | 0.01/0.1 pH | |
Accuracy | ±0.01 pH ±1digit | |
Input current | ≤1×10-12 A | |
Input impedence | ≥1×1012 Ω | |
Stability | ±0.01 pH/3h ±1 digit | |
Temperature compensation | (0 ~ 100)°C(manual or automatic) | |
mV | Range | -1,999mV ~ 0 ~ 1,999mV |
Resolution | - 200 mV ~ 0 ~ 200 mV: 0.1 mV;others:1mV | |
Accuracy | ±0.1% FS ±1digit | |
Conductivity | Range | Cond:0~200mS/cm divided into five ranges: (0.00~19.99)μS/cm (20.0~199.9)μS/cm (200~1999)μS/cm (2.00~19.99)mS/cm (20.0~199.9)mS/cm TDS:(0 ~ 100)g/L Salinity:(0 ~ 100)ppt Resistivity:(0 ~ 100)MΩ·cm |
Resolution | 0.01/0.1/1μS/cm 0.01/0.1 mS/cm | |
Accuracy | ±1.0% FS ±1digit | |
Temperature compensation | (0 ~ 50)°C(manual or automatic) | |
Electrode constant | 0.1 / 1 / 10 cm-1 | |
Temperature | Range | 0~100°C |
Resolution | 0.1℃ | |
Accuracy | ±0.5℃±1digit | |
Other Technical Parameters | Data storage | 1000 groups |
Storage content | Serial number, date, time, measuring value, measuring unit and temperature value | |
Power | AAA batteries × 3 (1.5V× 3) / DC5V adaptor ( USB port) | |
Dimension & Weight | Meter: (88×170×33 )mm / 313g;Portable case:(480×360×95)mm/3.2kg | |
IP rating | IP57 dustproof and waterproof |
1. SX823 portable pH/conductivity meter | 1unit |
2. 201T-Q plastic three-in-on pH electrode | 1pc |
3. 2301T-Q plastic conductivity electrode | 1pc |
4. pH standard buffer solution (4.00/7.00/10.01pH/50mL) | 1 bottle each |
5. Conductivity calibration solution (84μS /1413 μS/cm/12.88 mS/cm /50mL) | 1 bottle each |
6. PC-Link communication software disk | 1disk |
7. USB communication cable | 1pc |
8. USB adaptor (DC 5V) | 1pc |
9.Combined electrode clip | 1pc |
10. Manual | 1book |
11. Big portable case | 1pc |
Accessory Category | Description | Specifications |
pH combination electrode | 2501-C glass pH combination electrode | Suited for general water such as surface water, tap water, waste water and seawater, etc. BNC connector. |
2503-C glass pH combination electrode | Suited for turbid or colloidal solution such as milk, jam, water paint, cosmetics, waste water and sludge, etc. BNC connector. | |
2503D-C glass pH combination electrode | Suited for solution with low ionic strength and high purity water, BNC connector. | |
2015P-C surface pH combination electrode | Suited for medium with moist surface such as skin, paper, cloth, fruit, meat, colloidal solution and micro-solution, BNC connector. | |
ORP combination electrode | 301Pt-C ORP combination electrode | Test ORP, BNC connector. |
Conductivity electrode | 2310T-Q plastic conductivity electrode(K=10) | Suited for solution with polyelectrolyte such as seawater and strong brine, have automatic temperature Compensation function,4 pin connector. |
DJS-0.1-Q glass conductivity electrode(K=0.1) | Test conductivity of high purity water, there is also flow cell, have automatic temperature compensation function, 4 pin connector. | |
Glass flow cell | Match DJS-0.1-S electrode. | |
Temperature electrode | MP500-Q temperature sensor | Use with pH combination electrode, 4 pin connector. |
pH buffer | pH4.00 buffer | 500mL/250mL/50mL(bottle) |
pH6.86 buffer | 500mL/250mL/50mL(bottle) | |
pH9.18 buffer | 500mL/250mL/50mL(bottle) | |
pH7.00 buffer | 500mL/250mL/50mL(bottle) | |
pH10.01buffer | 500mL/250mL/50mL(bottle) | |
Conductivity standard | 84 μS/cm conductivity standard | 500mL/250mL/50mL(bottle) |
1413 μS/cm conductivity standard | 500mL/250mL/50mL(bottle) | |
12.88 mS/cm conductivity standard | 500mL/250mL/50mL(bottle) | |
146.6 μS/cm conductivity standard | 500mL/250mL/50mL(bottle) | |
1408 μS/cm conductivity standard | 500mL/250mL/50mL(bottle) | |
12.85 mS/cm conductivity standard | 500mL/250mL/50mL(bottle) | |
Electrode soaking solution | combination electrode soaking solution | 500mL/250mL/50mL(bottle) |
ORP standard solution | 222 mV ORP standard solution | 250mL/100mL/50mL(bottle) |
Portable case | Big portable case(480×360×95)mm | Match SX816, SX823, SX825, SX836 |
