SX713 Portable electrical conductivity meter water conductivity sensor

Name: SX713 Portable electrical conductivity meter water conductivity sensor
Brand: YANHE
Price: USD $180 - 200 / Set

FOB Price

USD $180 - $200 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port shanghai
Payment Terms:Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Shanghai, China

Brand Name:

YANHE

Model Number:

SX713

Product Description

The most cost effective portable conductivity meter, measurement of conductivity, TDS, salinity and resistivity of water solutions, suited for industrial and mining factories, water treatment engineering and environmental protection field, especially suited in field and on-site.

Introduction

Built-in microprocessor chips, intelligent functions such as automatic calibration, automatic temperature compensation, data storage, function set-up, automatic power-off and low voltage display.

Automatic identification of 8 conductivity standard calibration solutions, two options of standard calibration solutions: Europe and America series and China series.

Adopt advanced conductivity measurement technology, use conductivity electrode of constant K=1, only need one point calibration and meet the measurement precision requirement of 0.5μS/cm ~ 200 mS/cm.

Ability to switch among conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.

Conductivity measurement mode has the function of non-linear temperature compensation for high purity water.

Plastic conductivity electrode with automatic temperature compensation, fast response and accurate result.

Meter meets IP57 rating, equipped with calibration solution and portable case.

Specifications

Category	Product Name	Basic features and specifications
Conductivity	Measuring range	Conductivity:(0.00~19.99)μS/cm (20.0~199.9)μS/cm (200~1999)μS/cm (2.00~19.99)mS/cm (20.0~199.9)mS/cm TDS: (0 ~ 100)g/L Salinity: (0 ~ 100)ppt Resistivity:(0 ~ 100)MΩ·cm
	Resolution	0.01/0.1/1μS/cm 0.01/0.1 mS/cm
	Accuracy	Meter:±1.0% FS, Overall:±1.5% FS
	Temp. compensation range	(0 ~ 50)℃(manual)
	Electrode constant	0.1 / 1 / 10 cm-1
	Benchmark temperature	25℃,20℃ and 18℃
Other Technical Parameters	Data storage	200 groups
	Storage content	Series number, measuring value measuring unit and temperature,
	Power	Two AA batteries (1.5V x2)
	Size and weight	meter:(65×120×31)mm/180g;Suitcase: (360×270×76)mm/1.6Kg
	Quality and safety certification	ISO9001:2000, CE and CMC
Working Condition	Environment temperature	5 ~ 35 ℃(0.01grade)
	Environmental humidity	≤85%
	IP rating	IP57 Dustproof and waterproof

Standard Kit Includes

1. Model SX713 Conductivity/TDS/Salinity/Resistivity meter	1unit
2. 2301-S plastic conductivity electrode	1pc
3. 1413μS/cm conductivity standard solution (50mL)	1btl
4.Screw driver	1pc
5. Spare AA batteries	2pcs
6. Operation manual	1pc
7. Carrying case	1unit

Optional Accessories

Accessory Category	Description	Specifications
Conductivity electrode	2301-S Plastic conductivity electrode	K=1.0 cm-1,ATC, suited for conductivity measurement of general water solution, 8 pin connector.
	DJS-0.1-S Glass conductivity electrode	K=0.1cm-1,ATC, suited for pH measurement of of high purity water, 8 pin connector.
	Glass flow cell	Match DJS-0.1-S electrode.
Conductivity standard	84 μS/cm conductivity standard	500mL/250mL/50mL(bottle)
	1413 μS/cm conductivity standard	500mL/250mL/50mL(bottle)
	12.88 mS/cm conductivity standard	500mL/250mL/50mL(bottle)
	146.6 μS/cm conductivity standard	500mL/250mL/50mL(bottle)
	1408 μS/cm conductivity standard	500mL/250mL/50mL(bottle)
	12.85 mS/cm conductivity standard	500mL/250mL/50mL(bottle)
Portable case	Small portable case(255×210×50)mm	Match single electrode.
Portable case	Big portable case(360×270×76)mm	Match multi- electrode
