Home > Instruments & Meters > Analysis Instrument > pH Meter > MP522 Bench Top Precision PH/Conductivity/mV/Temp Meter ph ec Meter

MP522 Bench Top Precision PH/Conductivity/mV/Temp Meter ph ec Meter

Name: MP522 Bench Top Precision PH/Conductivity/mV/Temp Meter ph ec Meter
Brand: YANHE
SKU: 113449903
Availability: InStock

MP522 Bench Top Precision PH/Conductivity/mV/Temp Meter ph ec Meter thumbnail-1

MP522 Bench Top Precision PH/Conductivity/mV/Temp Meter ph ec Meter photo-1

US$ 720 - 800 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

YANHE

Model Number:

MP522

Contact Supplier Request Quote Chat Now

Shanghai Yanhe Instrument Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name YANHE

Model Number MP522

Introduction

Meter meets with the requirement of international GLP standards. Its features up to automatic calibration, automatic temperature compensation, data storage, timing measurement, clock display, RS-232 output, function setting and self-diagnose etc.

There are three different measurement modes: stable display mode; time measurement mode; continuous measurement mode.

Automatically recognize 13 kinds of pH buffer solution. User can choose anyone from four series of standard buffer solutions: Europe & USA series, NIST series, CHINA series and Self-defined series.

High purified water and ammonia added purified water pH measuring mode can be set up, especially suitable for electric power and petrochemical industry.

With EH redox potential measuring mode can directly display ORP value which against standard potential of hydrogen electrode.

Automatically recognize 8 kinds of conductivity standard solution. User can choose anyone from two series of solutions: Europe & USA series and China series.

Adopt advanced and original conductivity measurement technology, use 1 pc of conductivity electrode (K=1), it can meet measuring accuracy requirement for range within 0.5μS/cm ~ 200mS/cm by using only one-point calibration.

Automatically select conductivity measurement range, when measuring high pure water, equipment automatically enter into temperature compensation of nonlinear model, especially for electricity, microelectronics and the pharmaceutical industry requirements.

Meter has the only product serial number.

Dustproof and waterproof meter meets IP54 standards. All sockets are seal protected by the silica gel caps.

Specifications

pH	Measuring range Resolution Accuracy Input current Input impendance Stability Temp. compensation range	(-1.999 ~ 19.999)pH 0.1/0.01/0.001 pH Meter:±0.002 pH, connect meter with electrode:±0.01pH ≤1×10-12 A ≥3×1012 Ω ±0.002 pH/3h (0 to 100) ℃(automatic or manual)
mV	Measuring range(mV/ORP/EH) Resolution Accuracy	-1999.9mV ~ 0 ~ 1999.9mV 0.1mV ±0.03% FS
Conductivity	Measuring range Resolution Accuracy Temp. compensation range Electrode constant Reference temperature	Conductivity:(0.00~20.00)μS/cm (20.0~200.0)μS/cm (200~2000)μS/cm (2.00~20.00)mS/cm (20.0~200.0)mS/cm (200~2000)mS/cm(K=10) Resistivity:(0 ~ 100)MΩ·cm TDS: (0 ~ 100)g/L Salinity: (0 ~ 100)ppt 0.01/0.1/1μS/cm 0.01/0.1/1 mS/cm Meter:±0.5% FS,connect meter with electrode:±0.80% FS (0 ~ 50)℃(automatic ) 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 cm-1 25℃,20℃ and 18℃
Temperature	Measuring range Resolution Accuracy	-10℃~ 110℃ 0.1℃ 5~ 60℃range:±0.4℃ other range:±0.8℃
Other Technical Parameters:	Data storage Storage content Power Communication connector Size and weight Quality and safety certification	300 groups Measuring value series number, measuring value, temperature, ATC or MTC state, measuring date and time DC9V/300mA RS232 160 × 190 × 70mm/880g ISO9001:2008, CE and CMC
Working Condition	Environment temperature Environmental humidity IP rating	5 ~ 35 ℃(0.01grade) 15 ~ 30 ℃(0.001grade) ≤75% IP54 Dustproof and waterproof

Standard Kit Includes

1. Model MP522 Precision pH/Conductivity meter	1set
2. Model 602 flexible electrode holder	1pc
3. 201T-M plastic pH/ATC three-in-one combination electrode	1pc
4.2503-C glass pH combination electrode	1pc
5. MP500 temperature electrode	1pc
6. 2401-M conductivity electrode	1pc
7. pH standard buffer solution(pH4.00, pH7.00 and pH10.01/50mL)	1btl/each
8. 1413μS/cm conductivity standard solution(50mL)	2btls
9. 9V power adapter(meter use)e	1pc
10. RS-232 communication cable	1pc
11. MP522 communication software disk	1pc
12. Operation manual	1unit
13. Brief operation instruction	1unit
14. Packing List	1pc

Optional Accessories

Accessory Categry	Description	Specifications
pH combination electrode	201-C plastic combination pH electrode	Suitable for routine pH measurements, widely used, BNC connector.
	200-C plastic combination pH electrode	Suitable for routine pH measurements, long continuous, high precision, BNC plug.
	206-C plastic combination pH electrode	Smaller diameter electrode, suitable for small diameter container in a test, BNC connector
	201T-M plastic three-in-one combination pH electrode	Simultaneous measurement of pH and temperature, automatic temperature compensation, BNC + RCA plugs.
	2501-C glass combination pH electrode	For precise pH test, routine laboratory use, BNC plug.
	2503-C glass combination pH electrode	For precise pH test, used to measure complex samples, BNC plug.
	2503D-C glass combination pH electrode	For low-temperature solution and pure water pH measurement, BNC plug.
	2503G-C glass combination pH electrode	Suitable for high temperature solution pH measurements, BNC plug
	2503S-C glass combination pH electrode	For acid and high-temperature solution pH measurements, BNC plug.
	2015P-C plane combination pH electrode	For the surface and trace solution pH measurement, BNC plug.
Conductivity Electrode	DJS-0.1-M Pure water conductivity electrode	K=0.1 cm-1,Automatic temperature compensation, for testing the conductivity of high pure water, 4-pin plug
	2401-M Glass conductivity electrode	K=1.0 cm-1,Automatic temperature compensation, precision laboratory test for conductivity, 4-pin plug.
	2301-M Plastic conductivity electrode	K=1.0 cm-1,Automatic temperature compensation for laboratory and field testing, 4-pin plug.
	2310-M Plastic conductivity electrode	K=10 cm-1,Automatic temperature compensation, used to test seawater and concentrated salt water, etc., 4-pin plug
	Glass flow cell	Equipped with DJS-0.1-M electrode
ORP Composite electrode	301Pt-C Plastice ORP combination electrode	ORP measurement for conventional, wide range of uses, BNC plug
ORP Composite electrode	3501Pt –C Glass ORP combination electrode	ORP measurement of routine laboratory, test stability, fast response, BNC plug
Temperature Electrode	MP500 Temperature electrode	Stainless steel housing, fast response, high accuracy, RCA plugs
pH Buffer	pH4.00 buffer	500mL/250mL/50mL(bottle)
	pH6.86 buffer	500mL/250mL/50mL(bottle)
	pH7.00 buffer	500mL/250mL/50mL(bottle)
	pH9.18 buffer	500mL/250mL/50mL(bottle)
	pH10.01 buffer	500mL/250mL/50mL(bottle)
Conductivity Calibration Solution	84 μS/cm Conductivity Calibration Solution	500mL/250mL/50mL(bottle)
	1413 μS/cmConductivityCalibration Solution	500mL/250mL/50mL(bottle)
	12.88 mS/cmConductivityCalibration Solution	500mL/250mL/50mL(bottle)
	146.6 μS/cmConductivityCalibration Solution	500mL/250mL/50mL(bottle)
	1408 μS/cmConductivityCalibration Solution	500mL/250mL/50mL(bottle)
	12.85 mS/cmConductivityCalibration Solution	500mL/250mL/50mL(bottle)
Electrode soaking	pH(ORP)Combination Electrode Soaking Solution	500mL/250mL/100mL(bottle)
Electrode soaking	10^-5mol/L Sodium ion electrode soaking Solution	Equipped with 7801Sodium electrode . 500mL/250mL/100mL(bottle)
ORP standard solution	222 mV ORP Standard solution	250mL/100mL/50mL(bottle)
Electrode holder	Model 602 Flexible Electrode Holder	Nice appearance of the arc-type bracket, you can turn 360 degrees and vertical lift
	Model 601Stirring Type Electrode Holder	The electrode holder and magnetic stirrer combination of new products.
	Model 600 Electrode Holder	Cheap simple electrode holder
