TDSscan20 Pocket TDS Meter
- shanghai
You May Like
-
Bante900 Multiparameter Water Quality Meter PH/ORP/Ion/Conductivity/TDS/Salinity/Resistivity/Dissolved Oxygen Meter Supplier's Choice
-
Bante930 Precision Desktop PH/ORP/Ion Meter Ion Tester Price
-
PHS-3CW Digital pH Meter Price ph Meter Manufacturers in China
-
WXG-4 Cheap Manual Polarimeter
-
PHB-3 Pen Type ph Meter Water Quality Analysis Cheap ph Meter Manufacturers in China
-
SX725 Portable PH/Dissolved Oxygen Meter Multi-Parameter Meter
Product Details
| Place of Origin | Shanghai, China | Brand Name | YANHE | |
| Model Number | TDSscan20 |
Product Description
TDSscan20 Pocket TDS Tester
Multi-range pocket TDS tester, 3 points calibration, automatic temperature compensation, system menu contains 5 optional parameters. Accuracy: 1% F.S.
Features:
• Multi-range pocket TDS tester covers low, mid, high ranges.
• Standard platinum sensor provides fast and reliable measuring results.
• 1 to 3 points push-button calibration with automatic calibration solution recognition.
• Selectable TDS conversion factors for accurate measurement.
• Automatic temperature compensation provides reliable reading over the entire range.
• Auto-Hold function freezes stable measured value for easy viewing and recording.
• Battery indicator shows the remaining battery capacity.
• Auto-Power Off helps user effectively conserve battery life.
• System menu allows setting the 5 parameters, including the number of calibration points,
temperature units, hold function, auto-power off, etc.
• Reset feature automatically resumes all parameters back to factory default options.
• Replaceable electrode module reduces maintenance and replacement cost.
• Waterproof feature to ensure complete protection in harsh environments.

Applications:
• Research and education
• Water and wastewater treatment
• Environmental monitoring
• Electroplating and printing industry
• Aquaculture and hydroponics
• Beverage industry and other industrial applications
Model | TDSscan20 | |
TDS | ||
Range | 0~10ppt (Max. 20ppt, depending on factor setting) | |
Accuracy | ±1% F.S | |
TDS Factor | 0.1~1.0 (Default 0.5) | |
Calibration Points | 1 to 3 points | |
Calibration Solutions | 100ppm, 1000ppm, 10ppt | |
Temperature | ||
Range | 0~60°C, 32~140°F | |
Accuracy | ±1°C | |
Resolution | 0.1°C, 0.1°F | |
Calibration Points | 1 point | |
Calibration Range | Measured value ±10°C | |
Others | ||
Temperature Compensation | 0~60°C, 32~140°F | |
Temperature Coefficient | 2%/°C | |
Cell Constant | K=1 | |
Normalization Temperature | 25°C | |
Hold Function | Manual or Automatic | |
Power Off | Manual or Automatic (8 minutes after last key pressed) | |
Reset Function | Yes | |
Sensor Type | Order Code: ECSCAN-C1-10K | |
Power Requirements | 2×1.5V "AAA" Batteries | |
Battery Life | Approximately 200 hours | |
Dimensions | 185(L)×40(Dia.)mm | |
Weight | 100g | |
Order Code and Accessories:
Order Code: TDSscan20-E
* 2דAAA” Batteries
Order Code: TDSscan20-K
* TDS Calibration Solutions (71.8ppm, 744.7ppm, 7447ppm)
* Carrying Case
* 2דAAA” Batteries
