Help CenterRE-52AA Rotary Vacuum Evaporator Rotary Evaporator China
Related Products
-
RE-52CS Rotary Evaporator China Price of Industrial Rotary EvaporatorNegotiableMOQ: 1 Set -
RE-52CS-1 Lab Rotary Evaporator Laboratory Rotary EvaporatorsNegotiableMOQ: 1 Set
-
RE-52CS-2 Rotary Evaporator Price Cheap Vertical CondenserNegotiableMOQ: 1 Set
-
RE-2000A Rotary Vacuum Evaporator Price Cheap High QualityNegotiableMOQ: 1 Set
-
RE-5203 Water Baths Rotary Evaporator China Vertical Condenser Rotary EvaporatorNegotiableMOQ: 1 Set
APPLICATION:
1) This apparatus is one of the basic apparatus absolutely necessary for biochemistry organic chemistry,medical research institutes and universities. It is a key method for conncentration in experiments of prepartion and analysis.
FEATURES:
2) This apparatus apply rotating heat flask expand the evaporating area and putting it in water tank under the decomposing.
It in heating while rotating,the liquid in the flask will be spreaded and evaporated. The evaporating rate increases double than the general one.
3) This apparatus apply motor screw combination so long as push abutton motor main automatic up and down.
TECHNICAL DATE:
4) Input voltage:200V/50Hz
5) Input power:1.1Kw
6) Driving system:
Miniature,Survey-Quick motor combination integration.
Input power:40W
Circle rate:0-150r.p.m(Step less speed regulation).
7) Transmission mechanism:
Worm and worm gearing , up and down by travel lead motor screw
Distance between up and down(Max):150mm.
Aluminum-plastic jig lock the flask,hoder secure the glass evaporator safety and reliability.
The glass evaporator can be arbitrarily inclined within 0-45℃ along the horizontal direction.
8) Vacuum sealed:
It is sealed by the silicon rubber pad connected by the Fluoro-plastic tube to the standard entrance of flask.
9) Heating tank:
Heating capacity:1000W
Temperature range: From romm temperature to 100℃.
Chassis: D 220*106mm, round high quality stainless steel.
Temperature control:
Digit display temperature controller.
DIMENSIONS:
Dimension: 60*38*75cm(Length*Width*Height)
Weighs:25kg
