NJF-120A Lcd Digital Display Metallurgical Microscope

Name: NJF-120A Lcd Digital Display Metallurgical Microscope
Brand: YanHe
SKU: 113441577
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

YanHe

Model Number:

NJF-120A

Shanghai Yanhe Instrument Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name YanHe

Model Number NJF-120A

Theory Metallurgical Microscope

Drawtube Binocular

Description

	Excellent infinite Optical System.
	High Magnification Objective with Long Working Distance.
	Comfortable and Enjoyable Operation with low and Repetitive PositiOn Control knob.Easy.Safe and Reliable LamP Replacement Device.
	The Microscope is widely used for PCB board,LCD display and metaI structure observation and inspection.With Ingenious stand and convenient operation.it wiII be you r best choice.

Specification

			NJF-120A
Viewing Head	Binocular head		A
	Trinocular head		O
Eyepiece	WF10×/18		A
	WF8×/18		O
	WF10×/18 Eyepiece with 0.1mm cross hair		O
	WF12.5×/15		O
Objective	Infinitive Plan Achromatic Objective	4×/0.1/∞/- WD17.3mm	A
		5×/0.12/∞/- WD15.5mm	O
		10×/0.25/∞/- WD10.0mm	A
		20×/0.40/∞/- WD5.8mm	O
		40×/0.60/∞/0 WD2.9mm	A
		40×/0.65/∞/0 WD0.52mm	O
		50×/0.75/∞/0 WD0.32mm	O
		80×/0.90/∞/0 WD0.2mm	O
		100×/0.80/∞/0 WD2mm	O
Nosepiece	Quadruple nosepiece		A
Stage	Double layer mechanical stage150×140mm/75×50mm		A
Focusing	Coaxial fine & coarse adjustment		A
	Kohler Illumination, Epi-illuminator with iris aperture diaphragm and iris field diaphragm, 6V/20W Halogen lamp, Brightness adjustable		A
Illumination	Diascopic Illumination, 6V/20W Halogen lamp, Brightness adjustable		O
Filters	Blue, Green, Yellow & ground glass		A
Polarization Set			O
Specimen Presser	For metallurgical specimen preparation		O
Note: "A"Standard Outfit, "O"Optional
