Vibrometer

Name: Vibrometer
Brand: Soundwel
SKU: 113390983
Availability: InStock

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Soundwel

Model Number:

VG 120/200

Beijing Soundwel Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Soundwel

Model Number VG 120/200

VG 120 Vibrometer

l English display, menu type operation, simple operation. White backlight, can use in the dark environment

l Can measure the acceleration Peak value (Peak), root mean square (RMS) and peak displacement value. Real time display dynamic measurement histogram

l Adjustable low pass filter, can be set by the user casually

l Can store 10 point data (10 groups per point), 100 groups of measurement value and measuring time

l Automatically alarm function

l Built-in high performance lithium battery and charging control circuit, has very long working time and standby time

l Auto Calibration function

l Can be connected to external portable printer

VG 200 Vibrometer

l VG 200 is a kind of sub-mini Vibration Pen

l Can measure Vibration acceleration, velocity and displacement

l Lightweight and portable

l Use metal shell, good anti-interference performance

l Can measure the mechanical vibration caused by imbalance, disalignment, loose, bearing and gear fault

	VG120	VG200
Measuring Range	Acceleration: 0.1 m/s² ~ 199.9 m/s² Velocity: 0.01 cm/s ~ 19.99cm/s Displacement: 0.001mm ~ 1.999mm	Acceleration: 0.1m/s²~199.9m/s² Velocity: 0.1mm/s~199.9 mm/s Displacement: 0.001mm~1.999 mm
Frequency Range	Acceleration: 10Hz ~ 10kHz Velocity: 10Hz ~ 1kHz Displacement: 10Hz ~ 500Hz	Acceleration: 10Hz ~ 1kHz(LO) 1kHz ~ 15kHz(HI) Velocity: 10Hz ~ 1kHz Displacement: 10Hz ~500Hz
Accuracy	±5%	±5%
Display	128×64 dot matrix LCD,LED backlight	Three and half LCD display
Measuring Distance	0.15 ~ 1m	×
Sampling period	×	1s
Storage Capacity	10×10 measurement values	×
Power Supply	Lithium battery	2 LR44/SR44 batteries
Battery Life	100 hours (turn off backlight)	5 hours
Working Temperature	0℃ ~ 40℃	0℃ ~ 40℃
Working Humidity	≤80%RH	≤90%RH
