Factory Supply Directly 3 Pin Argentina Plug

US$ 0.5 - 1.5 MOQ: 2000 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

XRT

Model Number:

XRT-04

Shenzhen Yiwanda Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name XRT

Model Number XRT-04

Type Other, Flexible power cord

Application Home Appliance

Female End Type IEC

Specifications

Argentina plug
-MOQ: 500 Pieces
-Price:$0.8-1pcs
-Supply Ability:10000 PC/Week
-SAA , ROHS approed

Factory supply directly 3 pin Argentina plug

Features:

Rubber sheathed flexible cable/PVC
Various type of plug available
Cable working temperature should not exceed 65°C
Cable have a certain extent of temperature resistance and oil resistance, fit to work outside and work in the smeary environment.
Reach standard GB/T 18380.1-2001 vertical flame test.
When cable in temperature of 20°C the insulation resistance between conductors above 50MΩ.km.

Application: Rated voltage 300/500V, 350/750V, for Air conditioner, home appliance power supply.

Example: VDE H05RR-F, H05RN-F, H07RN-F

specification		Conductor	Normal thickness of insulation mm	Normal thickness of jacket mm	Over diameter mm	Max conductor resistance at 20°C ≤Ω/km	Ampere rating A
No. of core	normal cross-sectional area of conductor mm2	No. / Dia. mm	Normal thickness of insulation mm	Normal thickness of jacket mm	Over diameter mm	Max conductor resistance at 20°C ≤Ω/km	Ampere rating A
1	1.5	30/0.25	0.8	1.4	5.8~6.7	13.3	27
	2.5	49/0.25	0.9	1.4	6.5~7.2	7.98	37
	4	56/0.30	1.0	1.5	7.6~8.5	4.95	47
	6	84/0.30	1.0	1.6	8.5~9.5	3.30	52
2	1	32/0.20	0.8	1.3	8.2~9.1	19.5	17
	1.5	30/0.25	0.8	1.5	9.1~10.1	13.3	21
	2.5	49/0.25	0.9	1.7	10.9~12.4	7.98	30
	2×4	56/0.30	1.0	1.8	12.9~14.8	4.95	39
	3×6	84/0.30	1.0	2.0	14.7~16.6	3.30	51
3	3×1	32/0.20	0.8	1.4	8.9~9.9	19.5	12
	3×1.5	30/0.25	0.8	1.6	9.8~11.1	13.3	18
	3×2.5	49/0.25	0.9	1.8	11.7~13.4	7.98	26
	3×4	56/0.30	1.0	1.9	13.8~15.7	4.95	34
	3×6	84/0.30	1.0	2.1	15.7~17.6	3.30	43
