1.2379
1).Comparable steel:
|
ASTM (USA) |
JIS (Japan) |
GB(China) |
DIN(Germany) |
BOHLER (Austria) |
SS14 (Sweden) |
|
D2 |
SKD11 |
Cr12Mo1V1 |
DIN |
W -Nr |
K110 |
XW - 41 |
X155CrVMo12-1 |
1.2379 |
|||||
2).Chemical composition:
Standard |
C |
Si |
Mn |
Cr |
P≤ |
S≤ |
Mo |
V |
DIN |
1.50-1.60 |
0.10-0.40 |
0.15-0.45 |
11.0-12.0 |
0.030 |
0.030 |
0.60-0.80 |
0.90-1.10 |
ASTM/GB |
1.40-1.60 |
0.10-0.60 |
0.20-0.60 |
11.0-13.0 |
0.030 |
0.030 |
0.70-1.20 |
0.50-1.10 |
3).Delivery condition: EAF or ESR; hot rolled or forging; black,machined surface; Anneling ,Hardness:HBS≤229
4).Size conditions:
round |
Diameter(mm) |
Length(mm) |
|
14~500 |
2000~6000 |
|
|
Plate/sheet |
Thickness(mm) |
Width(mm) |
Length(mm) |
15~500 |
50~600 |
2000~6000 |
|
Square bars |
As customers’ requirements |
||
5).Surface conditions:scaled(black surface) / rough turned / milled / based on your requirements.
6).
Sizes we can provided | ||||||
Grade |
Forged |
Rolled |
||||
Rounds |
Flats |
Rounds |
Flats |
|||
width |
thickness |
width |
thickness |
|||
Hot working steel |
dia 50-500mm |
150-950 mm |
20-400 mm |
dia 12-50 mm |
150-610mm |
12-50 mm |
Cold working steel |
dia 50-400mm |
200-620 mm |
20-300 mm |
dia 12-50 mm |
150-610 mm |
15-50 mm |
Delivery of shipment:
There is no need to worry about shiping. It is convenient for our company to delivery products from Wuhan, Huangshi, Shanghai , ningbo port . Shipping port is choosed according to your requirements.
Wuhan Sanzhao Mould Steel Co., Ltd.
The company is consist of two subsidiary companies, specialized in manufacturing mould steels in Huangshi, where is famous for producing mould steel in the world.
Melting plant is Daye Weifeng Mining Technology Co.,Ltd, which is belong to Sanzhao’s biggest owner Mr. Liang, our chairman, who also the Vice-chairman of Huangshi Mould Steel Association. The plant possess steel making equipments : 3 set of electric furnace, 5 set of electro slag furnace and one set of VIDP specialized in producing high alloy steels. Auxiliary processing devices include annealing furnace, electric band saws, turning-lathes and milling machines . An advanced physics and chemical test methods, equipped with test facilities like spectrometer, standard chemical analysis lab, hardness meter, metallographic detection and ultrasonic testing to control good quality for customers. An advanced technical and management team with its members originally working and studying for large companies like Daye Special Steel Co.,Ltd. which is the base of Chinese special steel. They all have rich experience to operate all equipment from steelmaking to machines processing. The mill has formed a production capacity of heavy section steels 12000 tons each year for home and abroad ,including flats and round bars made from alloy steel, die steel, bearing steel and stainless steel.
Another is forging plant, Huangshi Sanli Forging Co.,Ltd., the partner of Sanzhao and also have 30% share belong to Mr. Liang. There is a 4500NK capacity hydraulic hammer to forging 10 tons of steel ingot, which is the biggest forging machine in Huangshi. The advanced auxiliary process devices are continuous heating furnace, bottom heating furnace, chamber furnace, annealing furnaces and finishing facilities like electric grinding wheel peeling machines and electric band saws.
