d3 Tool Steel
- Shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Steel Grade | D3 | Standard | AISI, ASTM, DIN | |
| Dimensions | bars:dia14-500mm,plate:15-400mm*50-1500mm | Place of Origin | Hubei, China | |
| Brand Name | Sanzhao | Model Number | 3Cr2Mo 3Cr2NiMnMo 10Ni3MnCuAi 4Cr13 3Cr17NiMo and so on. | |
| Technique | Forged | Application | Other, plastic mould steel | |
| Alloy Or Not | Is Alloy | Special Use | Mold Steel | |
| Type | Alloy Steel Bar |
Product Description
Specifications
1.good streghth and hardness2.we are manufacturers of alloy tool steel
3.ultrosonic test to SEP C/c
Cold-working D3 special alloy steel
AISI D3/DIN X210Cr12(1.2080)/JIS SKD1
1.Steel Grade
GB: Cr12
ASTM: D3
DIN : X210Cr12 (1.2080)
JIS: SKD1
2.Advantages
With high strength, good hardenability and wear resistance, it is a kind of cold-working tool steel which is widely used in the field of manufacturing die, punch, cold cut scissors, drill sets, gauges, drawing dies, press die, screw plate, drawing die and thread rolling die etc. since they inquire high wear resistance but low impact load.
3.Composition(%):
C : 2.00-2.30
Si : ≤ 0.40
Mn : ≤ 0.40
Cr : 11.50~13.00
P : ≤ 0.03
S: ≤ 0.03
4.Mechanical Property
Annealed Hardness: HB 269~217
Quenching Hardness: HRC 59~63
5.Delivery Condition
Forged + Annealed + Machining (Peeled/Turned)
6.Size Availability
We offer different shapes of steels, including square, flat and round.
