Help CenterAnimal Feed Plant Horse Feed Making Line 1t/h
Related Products
-
Small Farm Poultry Feed Making Line Farm Feed EquipmentUS$ 10,000 - 150,000MOQ: 1 Set -
Chicken Feed Pellet Plant Feed LineUS$ 10,000 - 1,500,000MOQ: 1 Set
-
China Pig Powder Making Line Animal Feed Line for SaleUS$ 10,000 - 150,000MOQ: 1 Set
-
Cattle Feed Processing Equipment Making Machine LineUS$ 10,000 - 150,000MOQ: 1 Set
-
Animal Feed Pellet/poultry Feed Pellet/livestock Feed Pellet Production LineUS$ 19,800 - 100,000MOQ: 1 Set
Feed processing plant
1. We are the professional manufacturer in China on the turn-key complete poultry feed plant;
2. We mainly manufacture the complete set of equipment or the production line. And we also produce silo, steel facture buildings;
3. With reasonable technology, high capacity and low energy consumption;
4. Centralized control: the analogue panel is adopted. All machines can be interlocked and safety. The operation is simple and convenient;
5. Wide applicable scope: The plant can produce both poultry or livestock feed and fish feed and is applicable for medium and small sized feed mills and breeding farms.
Features
(1) Simple structure and wide applicability. Small cover and low noise.
(2) Power feed and grass power can be made into pellet with only some liquid. Therefore, the water containing rate of pellet feed is the same as before when it is made into the pellet, which means that it is more conductive to storing.
(3) Pellets made by this machine are with high hardness,smooth surface and full of internal curing,which can not only improve digestion and absorption of nutrition but also kill the general pathogenic microorganisms and parasites. They can be used for feeding rabbits, fish, ducks, cattle, sheep and pigs, which have a higher economic benefit compared with mixed power feed.
1.animal feed pellet production line/feed pellet line makes 2-8 mm diameter animal feed pellets. such as 2-4mm diameter chick feed pellets and pig feed pellets.1.5-3mm fish feed pellets,2-5mm rabbit feed pellets,4-8mm cattle or sheep feed pellets, The last pellet length can be adjusted.
2.animal feed pellet production line/feed pellet line contains premixing,crushing, mixing, pelletizing ,cooling,crumbling ,screening and packing pellets parts. such as crusher, mixer, pellet mill, cooler ,crumbler ,cooler and all bins, screener,packing machine conveyors ect . we will design the full pellet line flow chart according to your raw materials character and specific requirement.
3.animal feed pellet production line/feed pellet line can make large pressure between rollers and ring die and ensure good pellet quality . pellet machine key spare parts are made by our CNC system , through high technical heat treatment ,which is high precision and good quality,
4.animal feed pellet production line/feed pellet line key pellet machine contains ring die and roller assemble inside, when works, roller assemble make rotary and ring die keep stable, in this way produce pellets by large pressure ,also it contains feeder and conditioner , which can adjust feeding materials speed and adding steam for soften materials, making materials fully cured and increase capacity.
4.animal feed pellet production line/feed pellet line key pellet machine list as below : please choose your ideal model and then we will design the full line flow chart accoridng to specific materials proportion and dimension.
5.animal feed pellet production/feed pellet line is hot selling more than 3000 sets per year, greatly welcome to visit. We have big discount for old customers.
1) The animal feed pellet machine has adopted gradeless speed-adjusting motor to feed and installed ferromagnetic magnet system, overload protection device and a limit switch to make sure the security. Besides, there are outer pellet-discharged structure and pressure or oil pump lubrication system.
2) Animal feed pellet machine,Before pressing the pellets,the raw materials should be powder with 15%-20% moisture.
3)our animal feed pellet machine can press 2-14mm pellets diameter,if you need different pellets diameter,just change the different ring die is ok.
1.The plants are applicable for various small and middle feed mills ,poultry and livestock farms ,aqua farms for producing poultry and livestock feed and common fish feed with annual capacity of 300-15000 kgs per hour.
2.The plants can produce both pellets and mash feed .The plant integrates all the equipments required in process of grinding ,mixing,pelletizing ,cooling ,screening ,lifting and conveying ,electric control etc.
3.The complete equipment is installed on the steel structure. The centralized control on analogue panel is adopted .All equipments can be interlocked for control and safety alarm device in available.
4.The operation is simple and convenient.
5.An advanced and semi-automatic feed mill can be built quickly with less floor space.It has features of easy installation ,convenient operation and centralized control.
6. Wide applicable scope: It can process different materials such as corn, maize, grass, grains, molasses, and some other raw materials.
7.Highly efficient one step gear transmission drive ensures maximum utilization ratio of energy.
8.Full stainless steel feeder; Variable-pitch anti-arch structure; Imported frequency converter control.
9.Stainless steel conditioner extends the conditioning and cooking time. Axial steam spraying port, improving feed cooking efficiency.
10.High precision driving main gear and pinion shaft adopt the carbonizing quenching and hard tooth surface grinding technology, resulting in smooth driving, low noise and long service life.
Q:Where are you?
A :Our factory is located in Henan Province,China .All our clients are warmly welcome to visit us!
Q:How to order?
A:After you decide to purchase, we will send you proforma invoice with our bank information, bring this PI to the bank, and ask to make T/T for deposit.
If you still don't understand, please don not hestitate to ask me.
Q:When to ship?
A: After your order comfirmed by deposit,we will notify you the rate of progress,if any minor problems, we will correct them asap and your machine can be ready within 7 days for a single set.
Q:How to install ?
A:we will offer you specific installation instructions and packing list together with our engineer to help setup the whole facility and make it run into normal use.
