Copper Coil Solar Water Heater

Copper Coil Solar Water Heater thumbnail-1
Copper Coil Solar Water Heater photo-1
US$ 100 - 500 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Pressurized
Circulation Type:
Direct / Open Loop (Active)
Contact Supplier Request Quote Chat Now
Zhejiang Jiadele Solar Energy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Evacuated Tube
Pressure Pressurized
Circulation Type Direct / Open Loop (Active)
Heating System Thermosyphon (Passive)
Connection Type Direct-Plug
Installation Freestanding
Housing Material Stainless Steel
Certification CE
Capacity 200
Place of Origin Zhejiang, China
Brand Name JIADELE

Specifications

Instant heat exchange; plentiful warm water for use
Fresh water quality
Works with pressure

Key Specification:

Instant heat exchange; plentiful warm water for use

Fresh water quality

Works with pressure

Output water temperature is stable, so it is very comfortable and safe to use

Hot and cold water flow is separated

Copper coil is tested and does not break; high grade materials are used



Material:

1)  Inner tank: stainless steel SUS304--0.50mm

2)  Vacuum tube: QB-AL-SS/CU-58-1800

3)  Outer tank: galvanized steel

4)  Frame: coated galvanized steel-1.5mm

5)  The material of insulation: polyurethane

6)  The reflector: aluminum

7)  Copper coil: Φ12mm, thickness 1.0mm


Remark:

Solar heat storage tank diameter(mm):360/480

Thickness insulated(mm):50

Max. fluid pressure(pa):1MPa

Operation fluid pressure(pa):0.4MPa

Coil connection(inch):1/2

Hot-outlet(inch):1/2

Cold-inlet(inch):1/2

Small tank connection(inch):1/2

Electric heater connection(inch):1.25Copper Coil Solar Water HeaterCopper Coil Solar Water Heater
