Jiadele U-type Pressurized Solar Collector

Name: Jiadele U-type Pressurized Solar Collector
Brand: Jiadele
SKU: 113331841

Jiadele U-type Pressurized Solar Collector thumbnail-1

Jiadele U-type Pressurized Solar Collector photo-1

US$ 100 - 200 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Jiadele

Model Number:

JDL-UT

Contact Supplier Request Quote Chat Now

Zhejiang Jiadele Solar Energy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Jiadele

Model Number JDL-UT

Type U Pipe

Application Solar Thermal

Pipe Material Copper

Specifications

we produce solar water heaters 12 years.
we have own design team and also produce solar water heater as customer design.

Specific data of the solar collector

Gross area: 18 tubes =2.924m²

Absorber area: 18 tubes = 1.453m²

Weight empty: 72Kg

Number of absorber elements: 18

Length of the tubes: 1800mm

Absorber pitch: 75mm

Type: Evacuated tube collector with U-type heat pipe

Material of the cover: aluminum

Material of the cover tube: borosilicate glass

Transmission of the cover tube: 86%

Outer diameter of the cover tube: 58mm

Outer diameter of the inner tube: 47mm

Thickness of the cover tube: 1.6mm

Heat transfer fluid: water-glycol

Absorber

Material of the absorber: Glass

Absorber coating: AL-SS/CU

Absorptive coefficient: 92%

Emissivity coefficient: 6%

Material of the absorber pipes: Copper

Layout of the absorber pipes: U-type heat pipe

Insulation

Thickness of the insulation in the header: 50mm

Material of the insulation in the header: cock wool

Limitations

Max.temperature: 99°C

Max: operating pressure: 6 bar

Specification

Material of inner manifold: copper, with stand pressure up to 0.6Mpa for pressurized system.

Outer of Manifold: Aluminum Alloy, thickness: 2.0mm

Frame: Aluminum Alloy, thickness: 2.0mm

Zhejiang Jiadele Solar Energy Co.,Ltd, is established in 1998. We are one of leading manufacturer and supplier of solar water heater in China. Non-pressurized solar water heater, pressurized solar water heater, split solar water heater, copper coil solar water heater, pressurized solar collector, non-pressurized solar water heater, U-type pressurized solar water heater .

For more products information, please go ahead to visite our website or contact with me directly.
