Flat Solar Collector With CPC Reflector

Name: Flat Solar Collector With CPC Reflector
Brand: JIADELE
SKU: 113322919

US$ 200 - 500 MOQ: 1 Set

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

JIADELE

Model Number:

JDL-CPC9-58/1.8

Zhejiang Jiadele Solar Energy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/ Ningbo/ Hangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name JIADELE

Model Number JDL-CPC9-58/1.8

Type Vacuum Solar Collector

Application Solar Thermal

Pipe Material Other, solar vacuum tube with heat pipe

Specifications

Flat Solar Collector with CPC reflector
2) SK SRCC CE ISO9001approved
3) highest efficiency
4) best quality
5) specia

Pressurized Solar Collector with CPC reflector

for water, space and process heating, series connection

Pipe material: Copper

Scope of delivery: Fully pre-assembled unit comprising

§ Evacuated tubes based on the thermos flask principle

§ Manifold with direct flow heat conduction unit and dry tube connection

CPC-reflector

No. of Evacuated Tubes		9
η (Aperture), DIN 4757-4 or EN 12975	%	64
Grid dimensions (length x height x depth)	m	1.95 x 0.96 x 0.1
Aperture area	m²	1.6
Weight	kg	30
Collector material		AI / Cu / glass / Silicone / PBT / EPDM / TE
Glass tube material		Borosilicate glass 3.3
Selective absorber coating material		Aluminium nitride
Glass tube (Ø ext./Ø int./wall thckn./tube lgth.)	mm	47/37/1.6/1800
Colour (aluminium frame profile, anodised)		Aluminium grey
Colour (plastic parts)		Black
