Product Details
Place of Origin: | Zhejiang, China | Brand Name: | cylinder, HUAJIE | Model Number: | Fire Extinguisher Cylinder, MFZ1-12 |
Product Description
Specifications
1.ISO9001 Fire Extinguisher Cylinder2.Portable type
3.CE/ISO2001:2008
4.OEM is acceptable
ISO9001 High Quality CO2 Fire Extinguisher Cylinder
products advantage :
1. Simple structure, flexible operation, convenient application.
2. Fast extinguisher speed, high efficiency, continuous orintermittent spraying.
3. Large Filling opening for extremely easy maintenance.
4. Capture nut head. Cap closure providing for easy alignment of presure gauge and detailed instruction after serving.highest efficiency dry powder with abrupt extinguishing effect.
5. High durability of steel cylinder as it is property coated with phosphate under treatment to resist corrosion and rust.
6. OEM is acceptable,Welcome your inquiry.
Products description:
It is made up of ABC dry powder, apply to extinguish solid material, inflammable liquids, combustible gases,organic solvents and voltage under the 5KV primary surface of the fire of the electrical equipment.
Technology data:
High Quality CO2 Fire Extinguisher Cylinder
Model | 2kg | 3kg | 5kg | 6kg | 8kg | 9kg | 10kg | 12kg |
Out diameter | Φ110mm | Φ130mm | Φ150mm | Φ163mm | Φ163mm | Φ180mm | Φ180mm | Φ180mm |
Volume | 2.42L | 3.55L | 5.95L | 7.0L | 9.0L | 10.7L | 11.65L | 13.5L |
Length | 310mm | 320mm | 400mm | 410mm | 505mm | 490mm | 530mm | 600mm |
Cylinder weight | 1.2kg | 1.4kg | 2.3kg | 3.0kg | 3.6kg | 4.0kg | 4.2kg | 4.3kg |
Dry powder weight | 2kg | 3kg | 5kg | 6kg | 8kg | 9kg | 10kg | 12kg |
Temperature | -20~55°C | -20~55°C | -20~55°C | -20~55°C | -20~55°C | -20~55°C | -20~55°C | -20~55°C |
Working Pressure(MAX) | 14Bar | 14Bar | 14Bar | 14Bar | 14Bar | 14Bar | 14Bar | 14Bar |
Testing Pressure | 25Bar | 25Bar | 25Bar | 25Bar | 25Bar | 25Bar | 25Bar | 25Bar |
Minimum Wall Thickness | 1.07mm | 1.14mm | 1.20mm | 1.24mm | 1.24mm | 1.30mm | 1.30mm | 1.30mm |
Product show:
Factory picture:
Our company, SHANGYU CITY HUAJIE FIRE CONTROL EQUIPMENT AND MATERIAL CO.,LTD.Found in 1985,and through almost 20 years development .Has been one of the best /largest /most competiive fire -fire fighting product manufacture in china .We are specialized in producing fire extinguishers and extinguishers accesorites ,In addition , we also produce accessories for fire fighting equipment such as fire hose,landing valve,jet spray branch pipe,hose coupling ,fire cabinet and other spare parts for safety equipment .
With its best work ,best quality and best service ,our factory welcome the friends from both at home and abroad for business cooperation .
YOUR SUCCESS IS OUR BUSINESS!
Outline of process
Product picture
Fire extinguisher packing information
Capacity | Size(CM) | G.W(KG) | N.W(KG) | The 20 foot container | |
0.5KG | 41*17*31 | 10 | 11.5 | 11 | 1250 boxes |
0.5KG | 41.5*33*31 | 20 | 23 | 22 | 660 boxes |
1KG | 50*20*32 | 10 | 18 | 17.5 | 860 boxes |
2KG | 36*24*41 | 6 | 20 | 19 | 785 boxes |
3KG | 46*29*15 | 2 | 11 | 10.5 | 1350 boxes |
4KG | 52*29*15 | 2 | 12.5 | 12 | 1200 boxes |
5KG | 52.5*29.5*15.5 | 2 | 15.32 | 14.32 | 1167 boxes |
6KG | 53*34*17.5 | 2 | 18 | 17 | 815 boxes |
8KG | 58*42*20 | 2 | 23 | 22 | 550 boxes |
9KG | 65*38*19 | 2 | 25 | 24 | 550 boxes |
10KG | 65*37*19 | 2 | 27.52 | 26.52 | 613 boxes |
12KG | 65*20*20 | 1 | 16.5 | 16 | 1030 boxes |
Remark:The above data are for reference only |
Quality certificates and Approval (only some of them):
Contact information:
