Filler Coating Machine Furniture /Wooden Floor/MDF/Table Tennis Tables Filling Machine /
US$ 200 - 2,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
TISAN
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Guangdong, China
Brand Name
TISAN
Model Number
760#,1100#,1420#
Usage
Other, fill the surface of the wood plates,such as flooring
Automatic Grade
Automatic
Gross Power
2.625 KW
Dimensions(L*W*H)
1480*1550*1300,1480*1850*1300,1480*2150*1300
Specifications
the machine is specially designed to fill the surface of the wood plates that contain large tubular fibers such as flooring1,The machine is specially designed to fill the surface of the wood plates that the contain large tubular fibers such as flooring,calcium cillicate boards and density plates,and it can also be used to fill the surface of plywood;
2,This machine can fill the sunken place,smooth the surface of execess paint and recycle the paint;
3,It is free from filling by hand so that the production efficiency is greatly improved and rework rates is reduce.It is really a necessity of the coating line.
4,The conveyor belts,painting roller and scraping roller adopt imported electric engine and their frequency speed control can regulate the speed separately so as to improve the effects of patch coating to the large extent.
| Model | TS-760# | TS-1100# | TS-1420# |
| Working width | 650MM | 1000MM | 1320MM |
| Working height | 2-80MM | 2-80MM | 2-80MM |
| Feeding speed | 0-30M/MIN | 0-30M/MIN | 0-30M/MIN |
| Feeding power | 0.75KW | 0.75KW | 1.5KW |
| coating wheel power | 0.75KW | 0.75KW | 1.5KW |
| Electricity wheel power | 0.375KW | 0.375KW | 0.375KW |
| Lining wheel power | 0.75KW | 1.5KW | 1.5KW |
| Power supply | 220V/380V50HZ | 220V/380V50HZ | 220V/380V50HZ |
| Machine dimension | 1480*1550*1300 | 1480*1850*1300 | 1480*2150*1300 |
| Machine weight | 0.9T | 1.1T | 1.3T |
