Specifications
Air to water heat pump1. Cooling and hot water at the same time
oling+hot water COP more than 7.5.
3.ETL,CE.
4.5kw~90kw
Air to water multi-function heat pump (with Copeland compressor)
| Model | MACHRW | 030ZA/(02) | 040ZA/(E02) | 050ZA/S(E02) | |
| Rated Output Water | L/h | 205 | 270 | 380 | |
| Rated Cooling Capacity | kW | 7.5 | 10.0 | 12.5 | |
| BTU/h | 25600 | 34200 | 42700 | ||
| Rated Input Power(Cooling) | kW | 2.40 | 3.20 | 4.00 | |
| Rated Input Current(Cooling) | A | 10.9 | 14.5 | 7.0 | |
| Rated Heating Capacity | kW | 9.0 | 12.0 | 15.0 | |
| BTU/h | 30800 | 41000 | 51200 | ||
| Rated Input Power(Heating) | kW | 2.70 | 3.60 | 4.50 | |
| Rated Input Current(Heating) | A | 12.3 | 16.4 | 7.9 | |
| Power Supply | V/PH/Hz | 220/1/50 | 220/1/50 | 380/3/50 | |
| Compressor | Rotary | Scroll | Scroll | ||
| Compressor Qty | 1 | 1 | 1 | ||
| Fan Qty | 1 | 1 | 2 | ||
| Noise | dB(A) | 55 | 55 | 57 | |
| Hot water side | |||||
| Water Connection | inch | 1 | 1 | 1 | |
| Water Flow Volume | m3/h | 3-4 | 4-5 | 5-6 | |
| Air condition side | |||||
| Water Connection | inch | 1 | 1 | 1 | |
| Water Flow Volume | m3/h | 1.5-2.5 | 2-3 | 2.5-3.5 | |
| Fan Direction | Horizontal | Horizontal | Horizontal | ||
| Refrigerant Gas Type | R410a | ||||
| Main Unit Net Dimensions(L/M/H) | mm | 1115/470/945 | 1115/470/945 | 1115/470/1250 | |
| Main Unit Shipping Dimensions(L/M/H) | mm | 1205/525/975 | 1205/525/975 | 1205/525/1280 | |
| Net Weight | kg | 112 | 125 | 150 | |
| Shipping Weight | kg | 132 | 145 | 170 |
1. Wide application
Widely used in hotels,restaurants,apartment houses, villas, factories and schools, sauna, bathroom, SPA association, beauty salon, fitness center, swimming pool, aquaculture, etc to applicate with various terminal equipment (fan coil, floor heating, radiators, temperature-holder tank etc.), combining indoor luxury decoration, maximizing satisfy user's requirements and comfortable. The modular structure is suitable for various sizes of engineering, office buildings, hotels, restaurants, cinema, shopping plaza, gymnasium, hospital etc., as the best choice of various public places.
2. High efficiency and energy saving
Using energy efficient scroll compressors heat exchanger (316 stainless steel material welded plate heat exchanger, high efficient S&C heat exchanger and rotory tube heat exchanger) small volume, heat exchang ability, so the same old products to improve energy efficiency is 10%.Comprehensive energy consumption is only65% of the solar energy water heater,25% of electric water heater. When it is cooling+heating,the COP will be more than 6.
3. Flexible configuration
The unit and tank flexible configuration.A different water tank to choose,pressure or open type connected to meet the different demands of clients.
Flexible installation position
Host appearance, compact tank to small occupation space for installation, conduit length of flexible connection.
4. Hot water circulation heat straight
55 degrees hot water heated one-time and got directly to use, improve comfort of water using and stable of unit. When stop to use water in a long time and the water temperature drops, unit will heat cyclely and automaticly.
5. Dual-core design
Heat pump, electric auxiliary heat integration together, super energy-saving and hot water in all-weather.
The advanced control technology of water
WEILO water pump built-in,with water flow protection, automatic filling and water level control, automatic water pressure test, hydrating pressurization control and Automatic constant temperature adjustment.
6. Integrated design,multi-protec and reliable
Integration design, system sealed welding completely, just conduit connections, without refrigerant pipe connections, simple and reliable connection installed. built-in protections of hot water flow and air flow, compressor exhaust temperature, high and low pressure compressor, compressors flow and power fault phase, power supply fault and lack of phase ,freeze protection, automatic defrost and automatic load adjusting etc built-in.Multiple protections.
7. Environment Friendly
Using refrigerant 407C or 410A, no damage,environment friendly.
