shen zhen uv curable green ink for pcb, UV halogen free pcb green mask

Specifications

It is a one-part type of solder resist ink with high precision, solvent free and 100% solid content.



UV Curable Solder Resist Ink  DH-8000

 DH-8000 is a one-part type of solder resist ink with high precision, solvent free and 100% solid content. Good adhesion and heat resistance.,accurate screen printing image with sharp edge and high accuracy can be transferred. Its good for high-speed printing process and hand printing process,and also be able to withstand the Lead(Pb) free refloat soldering process.





Product No.	DH-8000
Colour	Green,Black,Blue,White
Viscosity	120-170 PS  (25)
Particle size	<10µm
Scring printing	200-235mesh/Inch
Curing Conditions	800-1400 mj/ cm2,3-5m/min,30-50mins
Hardness	≥5H
Adhesion	100%
Heat resistance	260 ,10sec x3 times
Flammability	UL 94V-0
Electrical insulation	≥1x 1012-1x 1014Ω
packing	5kg/pot, 20kg/Carton
Shelf life at 25 in a dark place	9 months
