FEP Extrusion Line With Teflon Extruder Tandem Extrusion Line
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Singcheer
Model Number:
EXF20-45
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fluropolymer Cable Extrusion Line_high Temperature Cable LineNegotiableMOQ: 1 Set -
Pairing Machine Wire Stranding Machine Cable StranderNegotiableMOQ: 1 Set
-
Dual Coiler & Binding Machine_auto Cable CoilerNegotiableMOQ: 1 Set
-
Economic Solution for Conical Spool- Package SystemNegotiableMOQ: 1 Set
-
1250 Cantilever Pay-off & Take-upNegotiableMOQ: 1 Set
Place of Origin
China
Brand Name
Singcheer
Model Number
EXF20-45
Usage
Extruding
Specifications
Conductor: AWG24#-10#OD: 0.55mm-3.50mm
Min thickness for insulation: 0.076mm
Line speed: 150m/min
FEP Extrusion Line
Fluorine material is not only suitable for aerospace cable, also use for the electric product cable. The superfine wire has become an important part in product chain, which bring high challenge for superfine wire. Based on the market requirement, SINGCHEER developed suitable extrusion equipment for aerospace and electric wire & cabe, control the OD at the minimum size to satisfy market requirement.
EXF20-45
FEP Extrusion Line | |||||
Model |
EXF-20 |
EXF-30 |
EXF-45 |
||
Conductor(AWG)
|
42# - 28# |
36# - 16# |
26# - 10# |
||
Wire OD(mm)
|
0.18-0.7 |
0.3 - 2.0 |
1.0-5.0 |
||
Min thickness(mm)
|
0.05 |
||||
Material |
FEP / X-ETFE |
||||
Output(kg/h)
|
5 |
12 |
28 |
||
Max Line Speed |
300m/min
|
||||
Pay-off(mm)
|
150-300 |
150 - 300 |
400-630 |
||
Cooling |
Single cooling trough |
||||
Capstan |
300 belt taping |
300 belt taping |
500 belt taping |
||
Accumlt length(m)
|
200 |
||||
Take-up(mm)
|
150-300 |
150-300 |
400-630 |
||
EXF 30+45
