semi automatic paper carton filling machine /paper box packaging machine

Cangzhou hongfa packing machine technology research institute

Contact person :Miss Diana

MOB: 86 15127741651

QQ:1478488578

Skype:amywang8898

TEL/FAX:86 0317 4958886

1.  Technical parameter:

1)Capacity: 250ml

2)Output: 500-1000 box/hour

3)Packing material: cardboard carton / aluminum foil carton

4)Filling Temperature: cold filling: 2-50°C / hot filling 80-92°C

5)Overall power: 4.5KW

6)Size: (L*W*H): 2600*650*1800mm

7)Compressed air pressure: 1.0-1.4 Mpa,   Flow rate: 0.8-1.0M3/min, without oil, water and dust

8)Cooling water:Flow volume:≥20L/ min    Temperature: normal temperature

2. Features:

1)Workman put the carton on machine  ,inside is rotation type

2)automatic fold and tape into shape

3)Automatic filling and sealing

4)Automatic bevel hot sealing

5)Automatic fall box

6)PLC touch screen contriol system ,full computer control system

7)intelligent temperature controller ,automatic control the sealing temperature

3.Work flow :

 *******************************************************************************************************************

 WELCOME TO VISIT OUR FACTORY ANYTIME .

OUR CITY NAME IS CANGZHOU ,YOU CAN TAKE HIGH SPEED TRAIN FROM

SHANGHAI/BEIJING/HANGZHOU TO OUR CITY

Machine's details will send to you by mail
