TDL5M/6M/8M Tabletop Low Speed Refrigerated Centrifuge

Name: TDL5M/6M/8M Tabletop Low Speed Refrigerated Centrifuge
Brand: SJIA
SKU: 113166197
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

SJIA

Model Number:

TDL5M/6M/8M

Place of Origin:

Zhejiang, China

Ningbo Yinzhou Sjialab Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Brand Name SJIA

Model Number TDL5M/6M/8M

Place of Origin Zhejiang, China

Specifications

Mainly applied in a variety of fields such as biochemistry, medical treatment and public health, food safety, life science, etc.

Features:

1. With TFT true-color LCD widescreen touch monitor featured by intelligent control, touchable/Push-button operation models for simultaneous control.

2. Automatically record the operational parameters; can be directly started by RCF.

3. Use a brushless motor with high torque and variable frequency, with special combination of shock absorbers to keep the motor running smoothly.

4. With a complete steel structure and a stainless steel centrifuge cavity, it is sturdy and durable.

5. With triple protective layers of steel bushings to achieve secure and reliable operation.

6. Rotors at rest will be in standby and cool down.

7. With the inching function for momentary centrifugation.

8. With a motor gate lock mute mechanical & electrical integration.

9. Able to provide more than 20 kinds of operating modes for the user to programme and use freely.

10. 10 levels for speed-up/speed-down control.

Model	TDL5M	TDL6M	TDL8M
Maximum capacity	Swing rotor 4×300ml
Maximum Speed (r/min)	5500	6500	8000
RCF (×g)	4800	4800	5940
speed precision	±50r/min
Refrigeration system	Import fluoride-free compressor
Temp. control range	-20°C~+40°C
Temp. control precision	±1°C
Operation programs	20
Control and drive systems	AV Variable Frequency Motor, Microcomputer control, Direct drive
Total Power	1.8kw
Timer range	0-99h59min
Noise	≤65dB
Weight	110kg
Dimension (L×W×H)	630×760×400mm
