IP67 Approved LDV-100-12 waterproof over load protection single output 12V led driver
100W Single Output Waterproof Switching Power Supply LDV-100 series
SPECIFICATION | |||
OUTPUT |
|
||
Model |
LDV-100-12 |
LDV-100-24 |
|
DC Voltage |
12V |
24V |
|
Rated Current |
8.3A |
4.2A |
|
Current Range |
0-8.3A |
0-4.2A |
|
Rated Power |
100W |
100W |
|
Ripple & Noise |
120mVp-p |
120mVp-p |
|
Voltage Adj. Range |
±10% |
±10% |
|
Voltage Tolerance |
±1% |
±1% |
|
Inlet Stability |
±0.5% |
±0.5% |
|
Load Stability |
±0.5% |
±0.5% |
|
Setup, Rise, Hold Up Time |
800s,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC |
||
|
|
||
INPUT |
|
||
Voltage Range |
176~264VAC |
||
AC Current |
2A/115V 1A/230V |
||
Efficiency |
76% |
79% |
|
Inrush Current |
Cold-start current 30A/115V 60A/230V |
||
|
|
||
PROTECTION |
|
||
Over Load |
105%~150% |
||
Plusing hiccup shutdown Reset: auto recovery | |||
|
|
||
ENVIRONMENT |
|
||
Working Temp., Humidity |
-10℃~+60℃(Refer to output derating curve),20%~90%RH |
||
Storage Temp., Humidity |
-20℃~+85℃, 10%~95%RH |
||
Temp. Coefficient |
±0.03%/℃(0-50℃) |
||
Vibration |
10-500Hz,2G 10min,/1cycle,Period for 60min,Each axes |
||
|
|
||
SAFETY |
|
||
Withstand Voltage |
I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC |
||
Isolation Resistance |
I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC |
||
|
|
||
STANDARD |
|
||
Safety Standard |
UL1012TUV EN60950(IEC950,UL1950),IP67 |
||
EMC Standard |
CLSPR22(EN55022),IEC801-2,3,4,IEC555-2 Verification |
||
|
|
||
OTHERS |
|
||
Dimension |
221*44*69mm(L*W*H) |
||
Weight |
1.09Kg |
||
Yes. we do .
2 .What certification you have for the switching power supply ?
We have CE , ROHS , CCC , ISO9001 , IP67
3.How to Contact Us ?
Send your inquiry Details in the below, Click "Send" Now !
