XJ-H233 High Speed Quilting Embroidery Machine
Applications
Quilting processed goods: Clothing, sleeping bags, summer quilts, mattresses, bedspreads, seat cushions, leather etc.
Features
Integrate computerized quilting and embroidery
l Automatic color change, arbitrary head for quilting and embroidery
l Continuous quilting of independent pattern, skip quilting function
l Unlimited and continuous quilting and embroidery in Y direction, front and rear automatic tensioning systems
l Support USB flash memory, readable Tajima, Barudan, ZKS, SWF embroidery format.
l Independent presser foot operation to make the product have three-dimensional aesthetics
l Rolling shaft design in Y direction, cloth can be continuously sewn or quilted
Simple, convenient and feasible operation
l Rotating speed control, power-off protection, power-off memory function
l Broken line detection, rollback quilting and embroidery
l Advance and retreat function at a high or low speed
l Trimming system, trimming length control. Line drawing concentration system, stability and reliability
l When thread breakage,machine stop,&can automatically return to its needle breakage point after threading.
Technical Parameters
1.Model: High speed XJ-H255
2.Needle :2 needle
3.Head : 25head
4.Quilting Emb: X direction67.5mm/135mm
Y direction unlimited
whole face width:3375mm
5. Quilting speed: Max 850-900 rmp
Quilting meter for 1 hour: according how many stitch of design
6. Needle store: 120million
7. Pattern store: 100pcs
8.Main motor : Servo motor
9. X Y motor :Panasonic servo motor
10.Rotary hook: Jumbo rotary hook
11.Oil system :with automatic anointment
12.Power supply: three phase 380V /50hz
13.Power:4.5-5KW
14. Automatic origin . Thread breakage mending
15.Thread breakage detection .
