2 Years Warranty 350W 24V dc 400hz Power Supply

Name: 2 Years Warranty 350W 24V dc 400hz Power Supply
Brand: LEYU
SKU: 113138605

US$ 15 - 18 MOQ: 1 Piece

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

LEYU

Model Number:

FS-350-24 400hz power supply

Yueqing Leyu Electric Automation Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo / Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name LEYU

Model Number FS-350-24 400hz power supply

Output Power 301 - 400W

Output Type Single

Input Voltage Other, 180-264VAC

Output Voltage 24V

Output Frequency 60-100KHZ

Output Current 17.5A

2 years warranty 350W 24V dc 400hz power supply

Advantages

1. Reply your inquiry in 24 working hours

2. Customized design is avalible, OEM and ODM are welcomed

3. Delivery the goods to our customers all over the world with speed and prscision

4. Offer customers the lowest price with high quality power supply

Spc & Details show

SPECIFICATIONS
OUTPUT
Model	FS-350-12	FS-350-15	FS-350-24
DC Voltage	12V	15V	24V
Rated Current	29A	23.2A	14.6A
Current Range	0-29A	0-23.2A	0-14.6A
Rated Power	348W	348W	350.4W
Ripple & Noise	0-29A	0-23.2A	0-14.6A
Voltage Adj. Range	10~13.2V	13.5~18V	20~26.4V
Voltage Tolerance	±1%	±1%	±1%
Inlet stability	±0.5%	±0.5%	±0.5%
Load stability	±1%	±1%	±1%
Setup,Rise,Hold Up Time	800ms,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC

INPUT
Voltage Range	180~264VAC 47-63Hz
Efficiency	74%	78%	81%
Inrush Current	Cold-start current 35A
Leakage Current	<3.5mA/240VAC

PROTECTION
Over Load	105%~150%
	Protection type: plusing hiccup shutdown Reset:auto recovery
Over Voltage	13.8-16.2V	18~21V	27.6~32.4V
	Protection type: plusing hiccup shutdown Reset:auto recovery

ENVIRONMENT
Working Temp., Humidity	-10℃~+60℃(Refer to output derating curve),20%~90%RH
Storage Temp., Humidity	-20℃~+85V, 10%~95%RH
Temp. Coefficient	±0.03%/℃(0~50℃)
Vibration	10~500Hz,2G 10min,/1cycle,Period for 60min,Each axes

SAFETY
Withstand Voltage	I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD
Safety Standard	UL1012TUV EN60950(IEC950,UL1950)Approved
EMC Standard	CLSPR22(EN55022),IEC801-2,3,4,IEC555-2 Verification

OTHERS
Dimension	18312055mm(LWH)
Weight	0.8Kg
