Home > Electrical & Electronics > Power Transmission & Transformer > Transformer > B+C Lightning Protection Box

B+C Lightning Protection Box

Name: B+C Lightning Protection Box
Brand: thor
SKU: 113102191
Availability: InStock

B+C Lightning Protection Box thumbnail-1

US$ 300 - 1,000 MOQ: 100 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

thor

Model Number:

TRSX3-B+C

Contact Supplier Request Quote Chat Now

Zhejiang THOR Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo shanghai hongkong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name thor

Model Number TRSX3-B+C

Specifications:

TYPE	TRSX3-B+C
Operating voltage (Un):	420V/50Hz
ntinuous operating(Uc):	AC 420V
Voltage UP	≤2.0KV
Nominal discharge current(8/20us)(In):	80KA
Max dischage current (8/20us)(Imax):	160KA
Uc and off the ability to follow-up If the current	≤1.5KArms
Response time:	≤25 ns
Indicates the status of work	The green light to work properly,the module for the fault indication lights
Wiring	Series(can be converted to parallel)
Degree of protection	Class B Class C
Install conductor cross-section	≥16mm²
Case Material	Case Material
Installation Location	Total into the line side
Dimensions	29cm×40cm×12.2cm

Function and purpose:

Complex power lightning box (with counter) using the most advanced lightning protection technology - technology gap ignition advance, so that the discharge gap and the pressure limiting device also moves to non-distance match. The product can achieve Class B Power SPD energy levels, while maintaining the C-class power supply arrester limits the voltage level, through the flow of 160kA, for additional buildings, rooms, factories, enterprises, a total power , two, three mine, and other electronic equipment to ensure the safe operation of electrical equipment. Elegant appearance, easy to maintain.
The power supply box easy to install lightning protection, proper functionality, with the normal function of lightning detection and lightning, count the optional display, over-voltage alarm, wireless alarm and other functions, and the installation of thermal over-current tripping mechanism to meet electrical safety standards.......
