| Model No. | UN-3DSC-LaH | |
| Technique Parameter | Shooting range | min : 0.2 x 0.2 x 0.2mm max : 3 x 3 x 3m |
| Opereating specification | min: 0.35m , max : 3m | |
| vision | level:45° , vertical:57.5° , diagonal:69° | |
| Scanning Type | Laser | |
| Acquisition Time | about 18s | |
| Align Type | Auto Align | |
| Spatial x/y Resolution (2-Sigma Values) | @500mm:0.9 mm @1200mm:2 mm | |
| Depth Resolution (2 Sigma Value) | @500mm:1mm @1200mm:5mm | |
| VGA Depth Image | 640 x 480 (VGA) [pixel x pixel] | |
| Maximal Frames-per-Second Rate | 60 FPS | |
| Software | Anyprint 3D Scanning | |
| Voltage | 100-240V | |
| Maximal Power Consumption | 2.25W | |
| Data Format | 16 bit | |
| Depth Image Size | 640 x 480 (VGA) [pixel x pixel] | |
| Field of View (Horizontal, Vertical, Diagonal) | 57.5, 45, 69 ((H,V,D) [deg] | |
| Operation Range | 400-1200 mm | |
| Data Interface | USB 2.0 | |
| Operating Temperature | 10℃-40℃ | |
| Packing kit | tools | 1 set |
| CD | 1 set | |
| operation manual | 1 set | |
| packing list | 1 set | |
| warranty card | 1 set | |
| Certificates | CE FCC ROHS | |
Qingdao Unique Products Develop Co.,Ltd. was founded in 2001. We specialize in developing various 3D printers and printing materials and providing "3D Printing Application and Solution" to industry. We are developing the industrial Full-color-resin 3D printer, Super-capacitor-graphene 3D Printer, Human Corneal Bio 3D Printer and Bones Bio 3D Printer. And these projects will bring huge promotion to the intelligent healthcare industry, electric vehicle industry and life science field.
Advanced Features
1.We can make customs sizes(huge building volume).
2.High-precision,high density,high-speed,full-color scan to ensure high-quality scan data
3.Matched data processing software with autonomous proptety
4.The data can be exported as STL,PLY,OBJ,VRML etc, can be converted to other software such as Pro/e, Auto CAD,Geomagic Studio,Rapid Form etc.
5.Easy to understand, convenient to operate.
