2 Horse Float Angle Load Standard1.Rear barn door.
2.Double axle electric brake
3.Saddle Box
4.Rug Rack
2 Horse Float Angle Load Standard
QUALITY: Our horse floats are FULLY MEET the Australian standards,every link is subject to quality inspection and control strictly from raw materials purchase to the finished product, ensure perfection.
DELIVERY:Make production plan together with customers, PROVIDE production horse floats update weekly.Shipping arrangement timely,PROVIDE complete transport services.
RESEARCH AND DEVELOPMENT:We have experienced R & D team, can customized horse float,caravan trailer,gooseneck trailer according to customer requirements, can design new models according to customer's design,we have confidence to be able to provide comprehensive services.
Customer service: Provide QUICK-WEAR PARTSalong with each horse float.Provide corresponding services if customers have spare parts demand or seek technical support in the shortest time.
TRAILER MATERIALS |
CHASSIS MATERIAL |
double galvanized RHS(3.5mm-4.0mm) |
|
FRAME MATERIAL |
double galvanized RHS(2.5mm) |
||
BODY PANEL |
galvanized (1.2mm) |
||
ROOF |
special molded FRP 3340*1980 |
||
NUTS & BOLTS |
stainless steel |
||
WHEELS & TYRES |
WHEEL RIM |
14' steel alloy rims |
|
TYRES |
185R14C |
||
SPARE WHEEL |
one |
||
AXLES & SUSPENSIONS |
AXLES |
two special trailer axles |
|
LEAF SPRINGS |
tandem spring suspension 9 plates |
||
BRAKE SYSTEM |
double axle electric brake |
||
WINDOWS & DOORS |
FRONT WINDOW |
1220*610 |
|
SIDE WINDOWS |
three sliding windows |
||
VENTS |
two |
||
SIZE OF SIDE DOOR |
1755*615 |
||
REAR UPPER DOOR |
barn door |
||
RAMP DOOR |
2020*1210 |
||
REAR UPPER & RAMP DOOR STRUT |
high-intensity anti-rust strut |
||
HINGES FOR REAR UPPER DOOR |
special 6mm diameter copper hinges |
||
DRAWBAR |
DRAWBAR CHECKER PLATE |
1.2mm aluminium |
|
DRAWBAR SAFETY CHAIN |
two |
||
BRACING WHEEL |
one |
||
LIGHTS |
TRAILER PLUGS |
square 7 wick plug |
|
SIDE LAMPS |
6 |
||
TAIL LAMPS |
LED group |
||
REAR LAMPS STAND |
aluminum |
||
MUDGUARD |
MUDGUARD TYPE |
compact mudguard |
|
MUDGUARD CHECKER PLATE |
1.2mm aluminium in the front of mudguard |
||
PEDAL & ALUMINIUM STEP |
1.2mm aluminium decoration board |
||
INTERIOR & EXTERIOR |
CUPBOARD |
none |
|
FRIDGE |
none |
||
MICROWAVE |
none |
||
HORSE PROTECTION FRAME |
full padded |
||
HORSE RING |
four |
||
RUBBER MATTING FOR RAMP DOOR |
10mm rubber matting |
||
RUBBER MATTING FOR FLOOR |
10mm rubber matting |
||
RUBBER MATTING FOR INNER SIDE PANEL |
6mm rubber matting |
||
WOOD BOARD FOR FLOOR & RAMP DOOR |
18mm hardwood plywood |
||
RUG RACK |
full length side rug rack |
||
TACK BOX |
none |
||
SADDLE RACK |
in saddle box |
||
SADDLE BOX |
1200mm height for 2 saddles |
||
PAINTING |
single or multi-color |
||
DIMENSIONS |
OVERALL DIMENSIONS ( L x W x H: mm ) |
4210*2280*2590 |
|
BODY DIMENSIONS ( L x W x H: mm ) |
3340*1980*2230 |
||
INNER DIMENSIONS ( L x W x H: mm ) |
3210*1930*2155 |
||
|
LOADING CAPACITY IN 40'HQ CONTAINER
|
3 units |
||
