Creator 2 pins UVC254nm 55w 36w 30w 25w 20w 15w 10w 8w 6w ponds filter UV lamp sterilizer
CREATOR UV germicidal lamps with different bases, diameters, and lengths are available, which offer excellent efficiency. We supply two types of UV lamps, emitting UV-C wavelength at 253.7nm, ozone-free; while emitting UV-C wavelength both at 253.7nm and 185nm, ozone-generating.
Ultraviolet technology has been one of the most effective methods of water treatment and air purification. CREATOR UV lamp is the ideal solution for water/air disinfection application in a safe way, without using any chemicals.
Specifications:
1,Two-Pin, double ended UV germicidal lamps.
2,CREATOR UV lamps are made of high quality quartz.
3,Average lamp life is 13,000 hours.
4,Ozone-free lamps and ozone-generating lamps are for choice.
5,T5/T6 diameters, aluminum and ceramic bases can be chosen.
6,Quartz sleeves and ballasts are available.
Model |
Length |
Power |
Current |
Voltage at 50/60Hz |
Voltage at High Freq (V) |
UVC Output |
Base |
Life |
|
T5 Tube |
|
|
|
|
|
|
|
|
|
UVC4W |
135 |
4 |
170 |
28 |
23 |
9 |
0.9 |
G5 |
8000 |
UVC6W |
212 |
6 |
160 |
42 |
34 |
16 |
1.6 |
G5 |
9000 |
UVC8W |
288 |
8 |
150 |
56 |
45 |
21 |
2.1 |
G5 |
9000 |
UVC11W |
212 |
11 |
330 |
49 |
40 |
22 |
2.2 |
G5 |
13000 |
UVC16w |
288 |
16 |
350 |
54 |
44 |
36 |
3.6 |
G5 |
13000 |
|
T5, T6, T8 option |
|
|
|
|
|
|
|
|
|
UVC10W |
331 |
10 |
230 |
46 |
36 |
23 |
2.3 |
G13 |
13000 |
UVC15W |
437 |
15 |
340 |
51 |
44 |
47 |
4.7 |
G13 |
13000 |
UVC20W |
589 |
20 |
360 |
60 |
50 |
65 |
6.2 |
G13 |
13000 |
UVC25W |
437 |
25 |
600 |
43 |
41 |
70 |
7 |
G13 |
13000 |
UVC30W |
894 |
30 |
370 |
100 |
80 |
100 |
11.2 |
G13 |
13000 |
UVC36W |
1199 |
36 |
440 |
103 |
87 |
145 |
15.5 |
G13 |
13000 |
UVC55W |
894 |
55 |
780 |
87 |
70 |
160 |
17 |
G13 |
13000 |
UVC75W |
1199 |
75 |
850 |
110 |
85 |
220 |
26 |
G13 |
13000 |
l The the UV output value is tested in a laboratory where the wavelength is 254nm, the value may change in accordance with the environmental temperature change. <img src="/kf/HTB12aoiGVXXXXbJXpXXq6xXFXXXo/222354914/HTB12aoiGVXXXXbJXpXXq6xXFXXXo.jpg" alt="Creator 2 pins UVC254nm 55w 36w 30w 25w 20w 15w 10w 8w 6w ponds filter UV lamp sterilizer" width="680" height="452" style="line-height: 20px; font-size: 14px; font-family: Verdana, Arial, Helvetica, sans-serif;" ori-width="800" ori-height="534"><img src="/kf/HTB1wx7aIXXXXXb7XpXXq6xXFXXXN/222354914/HTB1wx7aIXXXXXb7XpXXq6xXFXXXN.jpg" alt="Creator 2 pins UVC254nm 55w 36w 30w 25w 20w 15w 10w 8w 6w ponds filter UV lamp sterilizer" ori-width="851" ori-height="423">
Product Features:
Hot cathode electrode, pre-heat start. average life ups to 13,000h
Can use same size fluorescent lamp bracket and holder, the tube diameter and lamp base
can be customized according to your need.
Aluminum caps or ceramic caps, anti-oxygenation and radiation resistance
Applications:
Aquarium disinfection
Water treatment
air cleaning and disinfection
Air conditioning pipe disinfection
Purifier
Advantage:
lThe inner surface of Tube is coated with a protective membrane to help to reduce uv output attenuation lower than 15%.
lThe UV lamp lifespan reach to 13,000 hours
The Science of UV:
UV light is divided into four distinct spectral areas-Vacuum UV (100 to 200 nanometers), UV-C (200 to 280 nanometers), UV-B (280 to 315 nanometers), and UV-A (315 to 400 nanometers). The UV-C spectrum (200 to 280 nanometers) is the most lethal range of wavelengths for microorganisms. This range, with 254 nanometers being the peak germicidal wavelength, is known as the Germicidal Spectrum.
src="/kf/HTB1KCMaGVXXXXb3XVXXq6xXFXXX3/222354914/HTB1KCMaGVXXXXb3XVXXq6xXFXXX3.jpg" alt="Creator 2 pins UVC254nm 55w 36w 30w 25w 20w 15w 10w 8w 6w ponds filter UV lamp sterilizer" style="width: 691px; height: 368px;" ori-width="550" ori-height="293">
How UVC affects microorganism DNA: g src="/kf/HTB1IsEbGVXXXXaNaXXXq6xXFXXXH/222354914/HTB1IsEbGVXXXXaNaXXXq6xXFXXXH.jpg" alt="Creator 2 pins UVC254nm 55w 36w 30w 25w 20w 15w 10w 8w 6w ponds filter UV lamp sterilizer" width="694" height="572" style="font-family: Verdana, Arial, Helvetica, sans-serif; font-size: 12px;" ori-width="472" ori-height="388">
<img src="/kf/HTB1mqcfGVXXXXcOXFXXq6xXFXXXR/222354914/HTB1mqcfGVXXXXcOXFXXq6xXFXXXR.jpg" alt="Creator 2 pins UVC254nm 55w 36w 30w 25w 20w 15w 10w 8w 6w ponds filter UV lamp sterilizer" style="width: 660px; height: 189px;" ori-width="708" ori-height="203">
UV technology for common bacteria and viruses the sterilization efficiency (the intensity of the UV radiation 30mW/cm2)
Species |
Name |
Kill 100% of the time required (in seconds) |
Species |
Name |
Kill 100% of the time required (in seconds) |
Bacteria |
Bacillus anthracis |
0.30 |
Bacteria |
Tuberculosis (branch) bacilli |
0.41 |
Diphtheria bacillus |
0.25 |
Vibrio cholerae |
0.64 |
||
Clostridium tetani |
0.33 |
Pseudomonas sp. |
0.37 |
||
Clostridium botulinum |
0.80 |
Salmonella spp. |
0.51 |
||
Shigella |
0.15 |
Intestinal fever genus |
0.41 |
||
E. coli |
0.36 |
Salmonella typhimurium |
0.53 |
||
Virus-like |
Adenovirus |
0.10 |
Virus-like |
Influenza virus |
0.23 |
Phage syncytial virus |
0.20 |
Poliovirus |
0.80 |
||
Coxsackie virus |
0.08 |
Rotavirus |
0.52 |
||
Love Ke virus |
0.73 |
Tobacco mosaic virus |
16 |
||
The Love Ke virus type I |
0.75 |
Hepatitis B virus |
0.73 |
||
|
Mildew Spore |
Aspergillus niger |
6.67 |
Mildew Spore |
Soft spores |
0.33 |
Aspergillus spp. |
0.73-8.80 |
Penicillium |
2.93-0.87 |
||
Dung fungi |
4.0 |
Toxigenic Penicillium |
2.0-3.33 |
||
Mucor |
0.23-4.67 |
Penicillium other fungi |
0.87 |
||
|
Water algae
|
Blue-green algae |
10-40 |
Water algae |
Paramecium genus |
7.30 |
Chlorella |
0.93 |
Green algae |
1.22 |
||
Nematode eggs |
3.40 |
Protozoan genus |
4-6.70 |
||
Fish disease |
Fung1 disease |
1.60 |
Fish disease |
Infectious pancreatic necrosis disease |
4.0 |
Leukoplakia |
2.67 |
Viral hemorrhagic |
1.6 |
Warning
Don’t look at the UV lamp directly when the UV lamp is igniting. Don’t irradiate the skin with UV-lamp. Hold a piece of ordinary glass before your eyes when you need to look at the UV-lamp. Please keep the surface of the tube clean to prevent the dust or the dirt from affecting the ultraviolet ray’s output. Please don’t touch the quartz glass with bare hands while installing the lamp and using it. The quartz glass can be cleaned by using alcohol tampon.
Why Choose Creator?
1: Focus on UV&IR industry for 15 years.
2: Make UV industry standard in China.
3:The Largest UV Gemicidal lamp manufacturer in China with most complete varieties of UV products
4:Product line covers all industries
5: Supply customized products for our customers.
6: Provide perfect solution for every customer.
7: Own modern digital industrial park for large-scale and standardized production.
8. Strong R&D team product with patent design, our lamps have 10% UV output higher than other competitorssrc="/kf/HTB1sWSaHXXXXXXbapXXq6xXFXXXb/222354914/HTB1sWSaHXXXXXXbapXXq6xXFXXXb.jpg" alt="Creator 2 pins UVC254nm 55w 36w 30w 25w 20w 15w 10w 8w 6w ponds filter UV lamp sterilizer" width="334" height="334" style="font-size: 16.363636016845703px; line-height: 24.545454025268555px;" ori-width="1000" ori-height="1000">
(Welcome to OEM to Customize Your Own Desgin)
Product Advantage:
Long life
The average life is 13,000 hours
High ultraviolet output
We adopt the high purity quartz tubes and advanced manufacturing technique to make the Creator’s lamps ultraviolet output 10% higher than others competitors.
Small light decay
The UV light decay is only 10-15% during the life time.
Reliability and stability
Advanced manufacturing technology and supervising quality guaranteed that our lamps are provided with dependability, stability, consistency.
Good cost performance
