Hikvision 700TVL High Resolution Speed Domme Camera ,PTZ With ir and Wiper

Hikvision 700TVL High Resolution Speed Domme Camera ,PTZ With ir and Wiper thumbnail-1
Hikvision 700TVL High Resolution Speed Domme Camera ,PTZ With ir and Wiper photo-1
US$ 1 - 500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Hikvision
Model Number:
DS-2AF7268(N)-AW
Contact Supplier Request Quote Chat Now
Yiwu Eastage Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Hikvision
Model Number DS-2AF7268(N)-AW
Type Analog Camera
Style Dome Camera
Sensor CCD
Technology Pan / Tilt / Zoom
Special Features Waterproof / Weatherproof

Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

                             HOFO Will Be Your Best Partner

Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

 Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiperHikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiperHikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

  • 1/4" Interline Transfer CCD
  • 700TVL high resolution;
  • Smart IR, 150m IR distance; Smart tracking
  • 36x optical zoom
  • 3D DNR; IP66 rating; Wiper

Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper



 Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper



Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper



Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper





Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

DS-2AF7268(N)-AW

Camera



Image Sensor:

1/4" Interline Transfer CCD


Effective Pixels:

PAL:976(H)×582(V)
NTSC:976(H)×494(V)


Horizontal Resolution:

Color: 700 TVL
B/W: 750 TVL


Signal System:

PAL/NTSC


Min.illumination:

Color: 0.02Lux/(F1.6, AGC ON),0.0008Lux /(F1.6, AGC ON, IRE×256)
B/W: 0.002Lux/(F1.6, AGC ON),0.00008Lux /(F1.6, AGC ON, IRE×256)
0 Lux with IR


White Balance:

Auto / Manual / ATW / Indoor / Outdoor


AGC:

Auto/Manual


S/N Ratio:

≥ 50dB


DNR:

3D DNR


BLC:

ON/OFF


Shutter time:

PAL: 1/3 ~ 1/10,000s, NTSC: 1/4 ~ 1/10,000s


Day&Night:

ICR


Digital Zoom:

16x


Privacy Masking:

8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously

 on the same video screen


Focus Mode:

Auto / Semi-automatic / Manual

Lens



Focal Length:

3.3-119mm, 36X


Zoom Speed:

Approx.4.4s(Optical Wide-Tele)


Angle of View:

57.1°-1.7°(Wide-Tele)


Aperture Range:

F1.4 – F4.2

Pan & Tilt



Pan Range:

360° endless


Pan Speed:

Pan Manual Speed: 0.1° -160°/s,
Pan Preset Speed: 240°/s


Tilt Range:

-2°-90° (Auto Flip )


Tilt Speed:

Tilt Manual Speed: 0.1°-120°/s,
Tilt Preset Speed: 200°/s


Proportional Zoom:

Rotation speed can be adjusted automatically according to zoom multiples


Number of Preset:

256


Patrol:

8 patrols, up to 32 presets per patrol


Pattern:

4 patterns, with the total recording time not less than 10 minutes


Power-off Memory:

Support


Park Action:

Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan


PTZ Position Display:

ON/OFF


Freeze Frame:

Support


Password Protection:

Support


Zone Scanning/Display:

Scanning within programmed zone, display zone title


Camera Title:

Programmable title display


Compass:

Support , the north can be set


Scheduled Task:

Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan


RS-485 communication diagnosis:

Including failure information, e.g., wrong address, baud rate errors, et.,

displayed on the video screen in text


Manchester code communication diagnosis:

Including failure information, e.g., wrong address, baud rate errors, et.,

displayed on the video screen in text


Smart-tracking:

Support

Infrared



IR Range:

150m


IR irradiation angle:

Adjustable by zoom

Alarm



Alarm Input:

2 inputs(7 inputs optional)


Alarm Output:

2 relay outputs, alarm response actions option

Input & Output



Monitor Output:

1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC

General



Menu Language:

English / Chinese


RS-485 Protocols:

HIKVISION, Pelco-P, Pelco-D, self-adaptive


Power Supply:

24V AC


Power Consumption:

Max. 52W


Working Temperature /Humidity:

-30 ℃-65℃(-22℉-149℉)(outdoor dome)
90% or less


Protection Level:

IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection


Wiper:

Support


Mounting:

Various mounting modes option


Dimensions:

Φ245 ×399mm (Φ9.65” ×15.71” ) (Outdoor)


Weight(approx.):

5.5kg(12.13Ibs)


Mount Option:



Long-arm wall mount: DS-1601ZJ; Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ; Power box mount:DS-1634ZJ



Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

♦ Quality Control

1. All raw materials are carefully selected and inspected.
2. Advanced production equipment is used and routinely inspected and serviced.
3. All operators and employees are thoroughly trained.
4. All products have passed the European Union RoHS standard and are CE, FCC certified.
5. All products must pass strict inspection before delivery.

6. Professional logistics personnel are employed to control the damage during the physical distribution of products.

♦ Cost Control

1. Our factories have been accredited in terms of ISO9001, and our advanced management system increases efficiency and reduces costs.

2. Bulk purchasing has reduced our material cost, and massive production have lowed each product cost.

3. Advanced production equipment such as our SMT production line provides a highly efficient production rate.
4. Reduction of any unnecessary surplus of products by strict stock control reduces our warehousing costs.

♦ Strong Tech Support

1. Presale: product consultation and solution design can be provided.
2. Sale: spares parts can be provided at a certain discount. Delivery time is approximately two weeks. Please note that delivery times may vary depending on the destination and transportation method.
3. After sale: We offer a 2-years warranty, which includes maintenance and technical support for all the products. Within the warranty period, exchanges and free maintenance are provided. If any quality issues occur, please contact us for technical support via telephone, email, or any method available on our site.
4. We can also provide project designs, customized products, online training, in-person training, and OEM services.



Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper

Hikvision 700TVL High resolution Speed domme camera ,PTZ with ir and wiper
