Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > Hikvision 32ch Dvr ,cctv Dvr, Security Dvr With HDMI

Hikvision 32ch Dvr ,cctv Dvr, Security Dvr With HDMI

Hikvision 32ch Dvr ,cctv Dvr, Security Dvr With HDMI thumbnail-1
Hikvision 32ch Dvr ,cctv Dvr, Security Dvr With HDMI photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Hikvision
Model Number:
DS-7232HVI-SH
Contact Supplier Request Quote Chat Now
Yiwu Eastage Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Hikvision
Model Number DS-7232HVI-SH

Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI

                             HOFO Will Be Your Best Partner

Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI

 Hikvision 32ch dvr ,cctv dvr, security dvr with HDMIHikvision 32ch dvr ,cctv dvr, security dvr with HDMIHikvision 32ch dvr ,cctv dvr, security dvr with HDMI

Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI

  •  Main stream supports up to WD1 resolution for and sub stream supports CIF/QCIF resolution
  •  Channel-zero encoding.
  •  HDMI/VGA output at 1920×1080P resolution
  •  Holiday recording schedule configuration

     l Network detection function.

Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI

 Hikvision 32ch dvr ,cctv dvr, security dvr with HDMIHikvision 32ch dvr ,cctv dvr, security dvr with HDMI

 Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI



Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI



Model



DS-7224HVI-SH

DS-7232HVI-SH

Video/Audio input

Video compression

H.264



Video input

24-ch

32-ch



Video input interface

BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive



Audio compression

G.711u



Audio input

4-ch, RCA (2.0 Vp-p, 1 kΩ)



Two-way audio input

1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)

Video/Audio output

HDMI/VGA output

1-ch, resolution:

1920 × 1080P / 60 Hz , 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz



CVBS output

1-ch, BNC (1.0 Vp-p, 75 Ω),

resolution: PAL: 704 × 576, NTSC: 704 × 480



Encoding resolution

WD1/ 4CIF / 2CIF / CIF / QCIF



Frame rate

WD1 / 4CIF @ 15 fps or

2CIF / CIF / QCIF @ 25 fps (P) / 30 fps (N)



Video bit rate

32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)



Audio output

1-ch, RCA (Linear, 1 kΩ)



Audio bit rate

64 Kbps



Dual-stream

Support;

Sub-stream: CIF / QCIF



Stream type

Video, Video & Audio



Synchronous playback

16-ch

Hard disk

SATA

2 SATA interface



Capacity

Up to 4TB capacity

External interface

Network interface

1, RJ45 10M /100M /1000M Ethernet interface



Serial interface

1 RS-485 interface, half-duplex



USB interface

2, USB 2.0



Alarm in

4



Alarm out

1

General

Power supply

12 VDC



Consumption

(without hard disk or DVD-R/W)

≤ 25 W



Working temperature

-10 ºC ~+55 ºC



Working humidity

10% ~ 90%



Chassis

19-inch rack-mounted 1U chassis



Dimensions

(W × D × H)

445 × 290 × 45 mm



Weight (without hard disk or DVD-R/W)

≤ 4 kg



Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI

Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI

♦ Quality Control

1. All raw materials are carefully selected and inspected.
2. Advanced production equipment is used and routinely inspected and serviced.
3. All operators and employees are thoroughly trained.
4. All products have passed the European Union RoHS standard and are CE, FCC certified.
5. All products must pass strict inspection before delivery.

6. Professional logistics personnel are employed to control the damage during the physical distribution of products.

♦ Cost Control

1. Our factories have been accredited in terms of ISO9001, and our advanced management system increases efficiency and reduces costs.

2. Bulk purchasing has reduced our material cost, and massive production have lowed each product cost.

3. Advanced production equipment such as our SMT production line provides a highly efficient production rate.
4. Reduction of any unnecessary surplus of products by strict stock control reduces our warehousing costs.

♦ Strong Tech Support

1. Presale: product consultation and solution design can be provided.
2. Sale: spares parts can be provided at a certain discount. Delivery time is approximately two weeks. Please note that delivery times may vary depending on the destination and transportation method.
3. After sale: We offer a 2-years warranty, which includes maintenance and technical support for all the products. Within the warranty period, exchanges and free maintenance are provided. If any quality issues occur, please contact us for technical support via telephone, email, or any method available on our site.
4. We can also provide project designs, customized products, online training, in-person training, and OEM services.



Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI

Hikvision 32ch dvr ,cctv dvr, security dvr with HDMI
