Constant Current DMX 512 Decoder 350mA

Specifications

Constant Current DMX 512 Decoder
with dip-switch,can set DMX address independently.
350mA*3Channels RGB constant current



DMX512  Decoder (350mA constatnt current), SW-DMX-D35



DMX common controller adopts the advanced micro control unit, it receives standard DMX-512 digital control signal and transformed it into PWM signal for driving LED;You could connect DMX module with DMX digital console to achieve dimming or various changes in procedures.



Technical Parameters:



Working temperature: -20-60 degree
Supply voltage: 12V/24VDC
Output: 3 channels
External dimension: L165xW68xH40 (mm)
Packing size: L180xW95xH60(mm)
Net weight: 320g
Gross weight: 355g
Static power consumption: 2W
Output current: each channel 350A
Output power: 5V:<5W,  12V:<12.6W,  24V:<25.2W

Package included:



 1 x DMX 512 Controller(DC12V)
