36led/72led Rigid Led Strip Lamp 5630 Smd White

36led/72led Rigid Led Strip Lamp 5630 Smd White thumbnail-1
36led/72led Rigid Led Strip Lamp 5630 Smd White photo-1
US$ 3.6 - 8 MOQ: 50 Pieces
Key Specifications
Get Latest Price
LED Light Source:
SMD
Type:
LED Bar Lights
Input Voltage(V):
DC12V
Contact Supplier Request Quote Chat Now
Shenzhen Starwire Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD
Type LED Bar Lights
Input Voltage(V) DC12V
Lamp Power 21.6
Lamp Luminous Flux(lm) 1500lm
Color Temperature(CCT) WW/NW/CW
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 35000
Lamp Body Material Aluminum
Certification CE, EMC, LVD
Emitting Color White
Place of Origin Guangdong, China
Brand Name SW
Model Number SW-A1919

Starwire DIY design of LED Linear Lights



 1. Customer could choose the right aluminum profile according to the installations -- we provide more than 20 choices for aluminum profiles.



2. Customer couls choose the right flex led strips according to the light demand -- we provide more than 20 choices for strips.



3. Because the easy cut function of aluminum profiles and flex led strips, so customized length, power, brightness, CRI are easy to get.



4. Our OEM service principles: fast response and professional advice.



36led/72led rigid led strip lamp 5630 smd white



Product Description

 Starwire LED Linear Lights Specification



Item No. Dimension(mm) LED Power Wattage Ra IP rate Lumen Color

1506/1707 led linear light

1. "U" shape, Smart size is suitable for most occasions installation.

2. 120pcs SMD3528/m give smooth light output.

3. There is female DC connector at one end, the wire length is 500mm

SW-A1506 500(L)*15(W)*6(H)

60pcs

SMD3528

 3.8W





DC12V

>80





IP40

 300lm



















WW:2800-3000K

NW: 4000-4500K

CW: 5500-6500K
1000(L)*15(W)*6(H)

120pcs

SMD3528

 7.7W 600lm



SW-A1707

 500(L)*17(W)*7(H)

30pcs

SMD5050

 5.8W 460lm
1000(L)*17(W)*7(H)

60pcs

SMD5050

 11.5W 920lm

1919 led linear light

1. "V" Shape can be corner lighting.

2. 72pcs SMD5630 /m give high brightness.

3. There is female DC connector at one end, the wire length is 500mm

SW-A1919 500(L)*19(W)*9(H)

30pcs

SMD5630

 10.8W DC12V  >80 IP40 750lm
1000(L)*19(W)*9(H)

72pcs

SMD5630

 21.6W 1500lm



36led/72led rigid led strip lamp 5630 smd white  36led/72led rigid led strip lamp 5630 smd white  36led/72led rigid led strip lamp 5630 smd white



Advantage of Starwire led linear light

1. Designed for flexible led strips.

2. Aluminum profile can dissipate heat much better.

3. High quality aluminum profile makes flex strip more elegant.

4. Provided two types of PC cover: Transparent cover & diffused cover.

5. "T" Shape:  Can be recessed mounted with high lumens transparent pc cover

    "U" Shape: Can be both recessed and surface mounted.

    "V" Shape: Can be corner lighting.

36led/72led rigid led strip lamp 5630 smd white 36led/72led rigid led strip lamp 5630 smd white

36led/72led rigid led strip lamp 5630 smd white





Our Services



1. A whole set includes: 1 PC cover+ 1 extrusion aluminum base+ 2 end caps+ 1/2 clips

2. Aluminum profile
    Surface: anodized silver (Color is changeable per customer's demand)

3. PC cover: diffuser/ opal/ transparent

4. Light source: 3528, 5050, 5630, 5730, 2835

5. Available lengths: 0.5m-3.0m ( Per customer's request)

6. Application: bathroom, refrigerator, ground lighting.

7. Assembly: Screw mounting, chain installation, clip-on installation and inline mounting.



36led/72led rigid led strip lamp 5630 smd white

 36led/72led rigid led strip lamp 5630 smd white





36led/72led rigid led strip lamp 5630 smd white

  36led/72led rigid led strip lamp 5630 smd white
